Quick Details
-
Model Number:
-
AKH-0.66/K-16
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Acrel
-
Theory:
-
electromagnetic induction
-
Output:
-
current
-
Maximum system voltage:
-
720V AC
-
Rated frequency:
-
50/60Hz
-
Protection level:
-
IP30
-
Operating temperature:
-
-25℃----+50℃
Quick Details
-
Use:
-
current measure
-
Mounting Type:
-
split core ct
-
Description:
-
measurement current, split core ct
-
Model Number:
-
AKH-0.66/K-16
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Acrel
-
Theory:
-
electromagnetic induction
-
Output:
-
current
-
Maximum system voltage:
-
720V AC
-
Rated frequency:
-
50/60Hz
-
Protection level:
-
IP30
-
Operating temperature:
-
-25℃----+50℃
General
Current Transformer (CT) is used to transform the high AC current to small easily manageable values. They are connected with the panel meter or relay and they can help to measure the current or protect the equipment.
|
Standards
|
|
|
IEC/EN61869-1, IEC/EN61869-2
|
|
|||
|
Security factor
|
|
|
FS<5
|
|
|||
|
Maximum system voltage
|
|
|
720V AC
|
|
|||
|
Rated frequency
|
|
|
50/60Hz
|
|
|||
|
Protection level
|
|
|
IP30
|
|
|||
|
Operating temperature
|
|
|
-25℃-+50℃
|
|
|||
|
Storage temperature
|
|
|
-40℃-+80℃
|
|
|||
Package
