Quick Details
-
Brand Name:
-
URE
-
Model Number:
-
XXR-P cutmini-01
-
Certificate:
-
COO
-
Product name:
-
mini Solar cells for 12v solar panel
-
material:
-
polycrystalline silicon
-
color:
-
blue
-
cell size:
-
6*1inch
-
busbar:
-
3BB Continuous Busbar
-
cell weight:
-
1.5 kg /720pcs
-
power watt:
-
0.778w
-
cell efficiency:
-
19%
-
Warranty:
-
3months-1year
Quick Details
-
Type:
-
PERC
-
Cell Efficiency:
-
19%
-
Place of Origin:
-
Taiwan, China
-
Brand Name:
-
URE
-
Model Number:
-
XXR-P cutmini-01
-
Certificate:
-
COO
-
Product name:
-
mini Solar cells for 12v solar panel
-
material:
-
polycrystalline silicon
-
color:
-
blue
-
cell size:
-
6*1inch
-
busbar:
-
3BB Continuous Busbar
-
cell weight:
-
1.5 kg /720pcs
-
power watt:
-
0.778w
-
cell efficiency:
-
19%
-
Warranty:
-
3months-1year
mini Solar cells cut poly Silicon 12v Solar panels for outdoor Charging Battery
mini solar cell |
|
| 3BB / 2bb continuous busbar | |
| efficiency | 19% |
| Impp | 1.55A |
| Solar cell grade | A grade |
mini Solar cells cut poly Silicon 12v Solar panels for outdoor Charging Battery
| Efficiency Code | 18 | 181 | 1820 | 1830 | 1840 | 1850 | 1860 | 1870 |
| Efficiency(%) | 18.0 | 18.1 | 18.2 | 18.3 | 18.4 | 18.5 | 18.6 | 18.7 |
| Pmax(W) | 0.442 | 0.4445 | 0.447 | 0.449 | 0.452 | 0.4545 | 0.457 | 0.46 |
| Vmp(V) | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 | 0.5 |
| Imp(A) | 0.884 | 0.889 | 0.894 | 0.898 | 0.904 | 0.909 | 0.9138 | 0.918 |
| Voc(V) | 0.59 | 0.59 | 0.59 | 0.5 | 0.59 | 0.59 | 0.59 | 0.59 |
| Isc(A) | 0.937 | 0.942 | 0.9476 | 0.9518 | 0.9582 | 0.9635 | 0.9686 | 0.973 |
| 600 pcs | 9600pcs | 460800pcs | 1000000pcs | |
| Box Size | 22*19*8CM | 23*25*22CM | 120*100*100CM*2 PALLETS | |
| GW | 1.5KG | 18KG | 675KG | 1350KG |
| Dimension | ||||||
| Solar Cell Thickness | 180µm ± 20µm | |||||
| Front(-) | |||||||||||
| Back(+) | 1.8mm wide silver/aluminum soldering pads, aluminum local back surface field. | |||||||||||
| Voltage | - 0.3324%/K |
| Current | +3.50 mA/K |
| Power | -0.342%/K |
Packaging & Shipping
| 100 pcs | 1400pcs | 50000pcs | 100000pcs | 2000000pcs | |
| Packing Size | 22*20*8CM | 23*28*25CM | 120*100*100CM*2 PALLETS | ||
| GW (KG) | 1.5KG | 15KG | 675KG | 1350KG | 2700kg |
| NW(KG) | 1.2kg | 12kg | 600KG | 1200kg | 2400KG |
