Quick Details
-
Brand Name:
-
EBASEE
-
Model Number:
-
EATS1
-
Max. Current:
-
125A
-
Product name:
-
PC Class ATS Automatic Transfer Switch
-
Model type:
-
EATS3
-
Design code:
-
Main breaker: 1: MCCB; 2: MCB
-
Circuit breaker:
-
C, N, P
-
Frame level:
-
32NA, 40NA, 63NA, 125NA
-
Rated current:
-
16, 25, 32, 40, 63, 125A
-
Controller type:
-
A, B, C, D
-
Rated working voltage:
-
220V AC 50Hz
-
Rated short-time withstand current:
-
5KA
-
Operating current:
-
3.5A
-
Certification:
-
IEC CE RoHS ISO9001 SEMKO TUV
Quick Details
-
Whether the smart:
-
NO
-
Max. Voltage:
-
220V
-
Place of Origin:
-
Shanghai
-
Brand Name:
-
EBASEE
-
Model Number:
-
EATS1
-
Max. Current:
-
125A
-
Product name:
-
PC Class ATS Automatic Transfer Switch
-
Model type:
-
EATS3
-
Design code:
-
Main breaker: 1: MCCB; 2: MCB
-
Circuit breaker:
-
C, N, P
-
Frame level:
-
32NA, 40NA, 63NA, 125NA
-
Rated current:
-
16, 25, 32, 40, 63, 125A
-
Controller type:
-
A, B, C, D
-
Rated working voltage:
-
220V AC 50Hz
-
Rated short-time withstand current:
-
5KA
-
Operating current:
-
3.5A
-
Certification:
-
IEC CE RoHS ISO9001 SEMKO TUV
Products Description
automatic transfer switch
Introduction
Model type EATS1 series automatic transfer switch is a new generation of the latest development products, ATS generally used to monitor the power supply circuits. When the power failure, ATS will changeover to backup power automatically, so that complete conversion power supply system.
At present, in particular suited for the important electricity power places where disallow to failure, in order to meet the needs of the scene, automatic switch has self-input and self-recover, self-input without self-recover, utility to utility, utility-
generators work with a variety of functions, the product applied in 240V, AC 50Hz, rated current from 10A to 1250A(CB class) autocratically switch products.
1. Alternative work by automatic and manual operation.
2. Monitoring the two sources, whether is loss phase, under voltage,loss voltage and such abnormal conditions, the indication show whether in located normal voltage;
3. There is a team with dry output contact for standby generators for start up and shut down.
4. Conversion type is self-input and self-recover
At present, in particular suited for the important electricity power places where disallow to failure, in order to meet the needs of the scene, automatic switch has self-input and self-recover, self-input without self-recover, utility to utility, utility-
generators work with a variety of functions, the product applied in 240V, AC 50Hz, rated current from 10A to 1250A(CB class) autocratically switch products.
Function
2. Monitoring the two sources, whether is loss phase, under voltage,loss voltage and such abnormal conditions, the indication show whether in located normal voltage;
3. There is a team with dry output contact for standby generators for start up and shut down.
4. Conversion type is self-input and self-recover
Product Paramenters
|
Rated working voltage
|
220V AC 50Hz
|
|
Changeover time delay
|
0.5s
|
|
Recovery delay
|
0.5s~90s continuous resettable
|
|
Under voltage changeover value
|
145V~210V continuous resettable
|
|
Overvoltage changeover value
|
230V~300V continuous resettable
|
|
Changeover time
|
Less than 4s
|
|
Type
|
CB type
|
|
Pole
|
3 pole, 4 pole
|
|
Certificate
|
CE, AAA
|
Features
1. Alternative work by automatic and manual operation, changeover type is auto switch and auto recovery
2. Full function of overload and short circuit protection
3.Monitoring the two sources, whether is loss phase, under voltage, loss voltage and such abnormal conditions, the indication show whether in located normal voltage
4.There is a team with dry output contact for standby generators for start up and shut down
5.conversion type is self-input and self-recover
1. Alternative work by automatic and manual operation, changeover type is auto switch and auto recovery
2. Full function of overload and short circuit protection
3.Monitoring the two sources, whether is loss phase, under voltage, loss voltage and such abnormal conditions, the indication show whether in located normal voltage
4.There is a team with dry output contact for standby generators for start up and shut down
5.conversion type is self-input and self-recover
|
Ambient temperature
|
-5~+40℃
|
|
Altitude
|
≤2000 m
|
|
Relative humidity
|
≤95%
|
|
Pollution level
|
II.
|
|
Installation location
|
Free from explosive danger, air or conductive dust which may cause corrosion of metal
|
