Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Hi-earns
-
Dimension(L*W*H):
-
720*635*765mm
-
Weight:
-
124
-
Rated power/speed:
-
20KW/3000rpm
-
Noise:
-
Low level
-
Fuel tank:
-
Best quality
-
Fuel tank capacity:
-
Optional
-
Lube oil capacity:
-
4
-
Shaft types:
-
Keyway shaft, taper shaft
-
Engine model:
-
HR2V98F
-
Starting system:
-
Electric
-
Certification:
-
CE/ISO9001
-
After Warranty Service:
-
Online support
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
Quick Details
-
Displacement:
-
1326cc
-
Emission Standard:
-
EURO 5
-
Power:
-
30HP
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Hi-earns
-
Dimension(L*W*H):
-
720*635*765mm
-
Weight:
-
124
-
Rated power/speed:
-
20KW/3000rpm
-
Noise:
-
Low level
-
Fuel tank:
-
Best quality
-
Fuel tank capacity:
-
Optional
-
Lube oil capacity:
-
4
-
Shaft types:
-
Keyway shaft, taper shaft
-
Engine model:
-
HR2V98F
-
Starting system:
-
Electric
-
Certification:
-
CE/ISO9001
-
After Warranty Service:
-
Online support
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
| Model | HR2V98F |
| Type |
V-twin cylinder, vertical, 4-stroke air-cooled diesel
engine |
| Combustion System | Direct Injection |
| Bore×Stroke (mm) | 98×88 |
| Displacement capacity (cc) | 1326 |
| Speed (rpm) | 3000 |
| Max.output (Kw) | 22 |
| Rated output (Kw) | 20 |
| Rated output (hp) | 28 |
| Fuel | o# or-10# light diesel oil |
| Lubricatiom oil volume (L) | 4 |
| Fuel oil consumption rate (g/kw.h) | 240 |
| Starting system | Electric |
| PTO rotation direction | It is clockwise as viewing from the flywheel end |
| Dimension (mm) | 720×635×765 |
| Gross weight (kg) | 124 |
| 20FT QTY | 81 |
