Quick Details
-
Ejector Stroke(mm):
-
300 mm
-
Ejector Force(kN):
-
275 kN
-
Theoretical Shot Volume(cm³):
-
4329 cm³
-
Injection Rate (g/s):
-
1040 g/s
-
Injection Weight (g):
-
4065 g
-
Screw diameter (mm):
-
105 mm
-
Screw L/D Ratio:
-
21.4
-
Distance between Tie Bars:
-
1010*1010
-
Weight (KG):
-
35500
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
1025 mm
-
Model Number:
-
BS800-III
-
Brand Name:
-
BORCHE
-
Power (kW):
-
40.9 kW
-
Clamping Force (kN):
-
8000 kN
-
Certification:
-
CE ISO9001
-
Machine weight:
-
35500KG
-
Injection pressure:
-
133MPa
-
Color:
-
Customized
-
Language:
-
English
-
Oil Tank Capacity:
-
1400L
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
1010 mm
-
Distance between Tie Bars(Height)(mm):
-
1010 mm
-
Mold Height(mm):
-
380 - 975 mm
-
Ejector Stroke(mm):
-
300 mm
-
Ejector Force(kN):
-
275 kN
-
Theoretical Shot Volume(cm³):
-
4329 cm³
-
Injection Rate (g/s):
-
1040 g/s
-
Injection Weight (g):
-
4065 g
-
Screw diameter (mm):
-
105 mm
-
Screw L/D Ratio:
-
21.4
-
Distance between Tie Bars:
-
1010*1010
-
Weight (KG):
-
35500
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
1025 mm
-
Model Number:
-
BS800-III
-
Brand Name:
-
BORCHE
-
Power (kW):
-
40.9 kW
-
Clamping Force (kN):
-
8000 kN
-
Certification:
-
CE ISO9001
-
Machine weight:
-
35500KG
-
Injection pressure:
-
133MPa
-
Color:
-
Customized
-
Language:
-
English
-
Oil Tank Capacity:
-
1400L
Product Description
BS
-III Machine Features
Injection Unit
Do
uble-injection cylinder
Double-carriage cylinder
Nozzle purge cover
Linear guide ra
il
Three kinds screw as option for every machine
Nozzle contact force adjustment function
Nozzle central device
Barrel cover
Low-speed high-torque Hydraulic motor
RPM sensor (4 times / 1 round)
Removable hopp
er rail
Clamping Unit
Mould fixing designation referring Euromap 2
Robot mechanical interface referring Euromap 18
Ejection distribution referring Euromap 2
Big operation room for ejection
Anti-pitch slider (above BT150)
Clamp transducer connect directly to cross head of toggle
Central oil lubrication
Hydraulic Unit
Variable displacement pump
One set sets core puller
Oil temperature alarm
Oil level meter and oil temperature indicator
Low pressure clamping function
Quick-clamping
Mould height adjustment by gear mechanism
Back-pressure control function
Suckback
Pressure relief valve for carriage moving (below BT650)
Oil cooler
High-precision bypass filter (above BT480)
Fiter block alarm (above BT800)
Self-sealing filter (above BT800)
Nozzle moving function √
Electric and control part
KEBA controller
Language (Chinese and English)
Data lock and operation password
SPC quality management
Alarm and parameter resetting record
PID temperature control
Screw protection function
Support current/voltage analogue output
Clamping force auto-adjust
CAN interface
Injection 6 stage/pressure holding 5 stage/charge 5 stage
Mold clamp/open 5 stage /ejection 2 stage
Certifications
Detailed Images
MOVING PL ATEN CLA MPING
SUPER LONG LASTING TIE BAR
INNOVATED INJECTION STRUCTURE
Mold platen Drawing
