Quick Details
-
Mounting Type:
-
thread
-
Description:
-
ultrasonic level sensor, ultrasonic level sensor
-
Manufacturing Date Code:
-
GXUM
-
Model Number:
-
GXUM
-
Place of Origin:
-
Shaanxi, China
-
Brand Name:
-
Kacise
-
Theory:
-
ultrasonic sensor, Ultrasonic Sensor
-
Output:
-
digital sensor, Analog SENSOR
-
Usage:
-
Level Sensor
-
Output signal:
-
analog, digital, switch
-
Measuring range:
-
Min. 0.5 m, Max. 60 m
-
Blind zone:
-
Min. 50mm, Max. 200mm
-
Casing:
-
Stainless steel, Plastic(ABS,PTFE)
-
Protection grade:
-
IP67
-
Item name:
-
ultrasonic level sensor
-
Application:
-
Liquid level, Grain level, Distance measuring
Quick Details
-
Use:
-
measuring liquid level
-
Series:
-
GXUM
-
Features:
-
Low power consumption
-
Mounting Type:
-
thread
-
Description:
-
ultrasonic level sensor, ultrasonic level sensor
-
Manufacturing Date Code:
-
GXUM
-
Model Number:
-
GXUM
-
Place of Origin:
-
Shaanxi, China
-
Brand Name:
-
Kacise
-
Theory:
-
ultrasonic sensor, Ultrasonic Sensor
-
Output:
-
digital sensor, Analog SENSOR
-
Usage:
-
Level Sensor
-
Output signal:
-
analog, digital, switch
-
Measuring range:
-
Min. 0.5 m, Max. 60 m
-
Blind zone:
-
Min. 50mm, Max. 200mm
-
Casing:
-
Stainless steel, Plastic(ABS,PTFE)
-
Protection grade:
-
IP67
-
Item name:
-
ultrasonic level sensor
-
Application:
-
Liquid level, Grain level, Distance measuring
Integrated RS485 Digital ultrasonic level sensor
Product Description
- High sensitivity
- Designed for outdoor or indoor environments
- 9V-28V supply with very low average current draw
- Sensor operates at 40 KHz, 112 KHz, 175 KHz, 300 KHz, 1 MHz
- Free run operation can continually measure and output ranger information
- Multi-kind output type such as analog (40-20mA, 0/1-5V, 0/1-10V), RS485, Can bus.
- Readings can occur up to every 33mS(30Hz) within 3meters or occur up to every 80ms(12.5Hz) within 10meters.
GXUM series
GXUS-M56
GXUS-M18; GXUS-M30
