Quick Details
-
Power (kW):
-
8 - 120 KW
-
Weight (KG):
-
15 KG
-
Input Voltage:
-
AC220V/380V±15%
-
Rated Current:
-
20 - 160A
-
Use:
-
Welding, Cutting
-
Input voltage:
-
AC220V/380V±15%
-
Frequency(HZ):
-
50/60
-
Rated input power(KVA):
-
8 - 120 KW
-
Rated input current (A):
-
20 - 160A
-
Rated output voltage (V):
-
Different
-
No-load voltage(V):
-
250-400
-
Efficiency(%):
-
80% - 90%
-
Current adjustment range (A):
-
20 - 140
-
Weight(KG):
-
Around 15
-
Function:
-
Welding, Cutting
-
After Warranty Service:
-
Video technical support, Online support, Spare parts
-
Local Service Location:
-
None
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
DELIXI
-
Warranty:
-
12 Months
-
Power (kW):
-
8 - 120 KW
-
Weight (KG):
-
15 KG
-
Input Voltage:
-
AC220V/380V±15%
-
Rated Current:
-
20 - 160A
-
Use:
-
Welding, Cutting
-
Input voltage:
-
AC220V/380V±15%
-
Frequency(HZ):
-
50/60
-
Rated input power(KVA):
-
8 - 120 KW
-
Rated input current (A):
-
20 - 160A
-
Rated output voltage (V):
-
Different
-
No-load voltage(V):
-
250-400
-
Efficiency(%):
-
80% - 90%
-
Current adjustment range (A):
-
20 - 140
-
Weight(KG):
-
Around 15
-
Function:
-
Welding, Cutting
-
After Warranty Service:
-
Video technical support, Online support, Spare parts
-
Local Service Location:
-
None
Product Description
| Product Name | MMA Welding Machine | MMA Welding Machine |
| Product number | ZX7-315D | ZX7-315DD |
| Model remarks | Single board ordinary 8 capacitors | Multi-board buttons |
| Input voltage | AC220V/380V±15% | AC220V/380V±15% |
| Frequency (HZ) | 50/60 | 50/60 |
| Rated input current (A) | 26.1 | 29/18 |
| Rated input capacity (KVA) | 5.45 | 6 |
| Rated output voltage (V) | 25.4 | 25.6 |
| No-load voltage (V) | 70 | 75 |
| Current adjustment range (A) | 20-140 | 20-150 |
| Load duration (%) | 30 | 30 |
| effectiveness(%) | 85 | 85 |
| Power Factor | 0.7 | 0.7 |
| Product size (mm) | 150mm*230mm*365mm | 260mm*145mm*200mm |
| Packing size (mm) | 460mm*270mm*350mm | 390mm*255mm*320mm |
| Net weight (KG) | 4.28kg | 3.9kg |
| Gross weight (KG) | 5.10kg | 4.8kg |
