Quick Details
-
Customized support:
-
Color
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
LISUN
-
Model Number:
-
LMS-6000
-
Wavelength Range:
-
380-780nm
-
Rang of wavelength::
-
380nm~780nm( visible sight)
-
Accuracy of wavelength::
-
±0.5nm
-
Accuracy of chromaticity coordinate::
-
±0.003
-
Correlated Color Temperature range::
-
1500~25000K (±3%)
-
Sample:
-
Available
-
Spectral resolution:
-
±0.2nm
-
Reproducibility:
-
±0.5nm
-
Accuracy of chromaticity coordinate:
-
±0.005
-
Correlated color temperature CCT:
-
1, 000K ~ 100, 000K (±0.6%)
-
Illuminance range:
-
5~200,000lx
Quick Details
-
Warranty:
-
2 years
-
Size:
-
8cm*5cm*3cm
-
Weight:
-
3 KGS
-
Customized support:
-
Color
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
LISUN
-
Model Number:
-
LMS-6000
-
Wavelength Range:
-
380-780nm
-
Rang of wavelength::
-
380nm~780nm( visible sight)
-
Accuracy of wavelength::
-
±0.5nm
-
Accuracy of chromaticity coordinate::
-
±0.003
-
Correlated Color Temperature range::
-
1500~25000K (±3%)
-
Sample:
-
Available
-
Spectral resolution:
-
±0.2nm
-
Reproducibility:
-
±0.5nm
-
Accuracy of chromaticity coordinate:
-
±0.005
-
Correlated color temperature CCT:
-
1, 000K ~ 100, 000K (±0.6%)
-
Illuminance range:
-
5~200,000lx
Product Description
| LISUN Model | Function | Wave Range |
| LMS-6000 | illuminance (lux), E(Fc), Ee(W/m2), Tc (K), Duv Correlated Color Temperature (CCT), Chromaticity Coordinates, CRI, Purity, Peak Wavelength, Dominant Wavelength, Half Bandwidth, Center Wavelength, Centroid Wavelength, Total Color Difference, Brightness Difference, Red-Green Degree, Yellow-Blue Degree, CCT Difference, SDCM Diagram, Spectrum Diagram | 380-780nm |
| LMS-6000B | LMS-6000 Parameters+Blue Light Hazard Weighted Irradiance according to GB/T20145, CIE S009/E:2002 | 350-800nm |
| LMS-6000BF | LMS-6000 Parameters+Flicker test, Blue Light Hazard Weighted Irradiance according to GB/T20145, CIE S009/E:2002 | 350-800nm |
| LMS-6000F | LMS-6000 Parameters+Flicker test | 380-780nm |
| LMS-6000L | cd/m2, fL, Tc (K), Duv Correlated Color Temperature (CCT), Chromaticity Coordinates, CRI, Purity, Peak Wavelength, Dominant Wavelength, Half Bandwidth, Center Wavelength, Centroid Wavelength, Total Color Difference, Brightness Difference, Red-Green Degree, Yellow-Blue Degree, CCT Difference, SDCM Diagram, Spectrum Diagram | 380-780nm |
| LMS-6000P | LMS-6000 Parameters+PAR, PPFD, YPFD, Blue-purple irradiance Eb, Yellow-green irradiance Ey, Red-orange irradiance Er, Ratio of red and blue radiation Erb_Ratio | 380-800nm |
| LMS-6000S | LMS-6000 Parameters+PAR, PPFD, YPFD, Blue-purple irradiance Eb, Yellow-green irradiance Ey, Red-orange irradiance Er, Ratio of red and blue radiation Erb_Ratio, Rf and Rg according to TM-30 | 350-950nm |
| LMS-6000UV | UV-A, UV-B, UV-C and UV total Radiant Irradiance, UV hazard irradiance, UV spectrum, Dominant Wavelength, Peak signal, Start wavelength, End wavelength. Please click here to see the LMS-6000UV Test Report . | 200-400nm |
| LMS-6000SF | LMS-6000 parameters+Flicker+Plant Lighting parameters+TM-30 | 350-950nm |
| LMS-6000I | Input and Output Control via RS485 | 380-780nm |
| LMS-6000C | LMS-6000 parameter without PC software | 380-780nm |
