Quick Details
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
31 kN
-
Theoretical Shot Volume(cm³):
-
154 cm³
-
Injection Rate (g/s):
-
144 g/s
-
Injection Weight (g):
-
144 g
-
Screw Speed (rpm):
-
1 - 180 rpm
-
Screw diameter (mm):
-
35 mm
-
Screw L/D Ratio:
-
20
-
Distance between Tie Bars:
-
360*360mm
-
Weight (KG):
-
3100 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
320 mm
-
Brand Name:
-
WATON
-
Power (kW):
-
9 kW
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Screw Diameter:
-
35mm
-
Injection Volume:
-
154g
-
Clamping force:
-
900Kn
-
space between tie bars:
-
360*360MmXmm
-
Oil tank capacity:
-
160L
-
Opening Stroke:
-
320mm
-
Power(W):
-
9kw
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
360mm
-
Distance between Tie Bars(Height)(mm):
-
360mm
-
Mold Height(mm):
-
150 - 360 mm
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
31 kN
-
Theoretical Shot Volume(cm³):
-
154 cm³
-
Injection Rate (g/s):
-
144 g/s
-
Injection Weight (g):
-
144 g
-
Screw Speed (rpm):
-
1 - 180 rpm
-
Screw diameter (mm):
-
35 mm
-
Screw L/D Ratio:
-
20
-
Distance between Tie Bars:
-
360*360mm
-
Weight (KG):
-
3100 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
320 mm
-
Brand Name:
-
WATON
-
Power (kW):
-
9 kW
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Screw Diameter:
-
35mm
-
Injection Volume:
-
154g
-
Clamping force:
-
900Kn
-
space between tie bars:
-
360*360MmXmm
-
Oil tank capacity:
-
160L
-
Opening Stroke:
-
320mm
-
Power(W):
-
9kw
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
| Device | Item | Model | B | |
| Injection Device | Screw diameter | mm | 35 | |
| Screw L/D ratio | L/D | 20 | ||
| Theoretical shot volume | cm3 | 154 | ||
| Injection weigt | g | 144 | ||
| Injection pressure | Mpa | 179 | ||
| Screw speed range | r/min | 0~180 | ||
| Making-up Device | Clamping force | KN | 900 | |
| Clearance between tie bars | mm | 360×360 | ||
| Opening stroke | mm | 320 | ||
| Max.Mould height | mm | 360 | ||
| Min.Mould herght | mm | 150 | ||
| Ejector force | KN | 31 | ||
| Ejector stroke | mm | 100 | ||
| Other | Pump power | KW | 9 | |
| Heating power | KW | 6.5 | ||
| Oil tank capacity | L | 160 | ||
| Machine weight | t | 3.1 | ||
| Weight dimension | mmm | 4.2×1.1×1.7 | ||
