Quick Details
-
Dimension(L*W*H):
-
6300*1500*2440mm
-
Warranty:
-
Within one year
-
Weight (KG):
-
7600 kg
-
Type:
-
Rubber Calender
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
roller:
-
cold hard cast iron
-
transmisson system:
-
roller ball bearing
-
gearbox:
-
hardened teeth gearbox
-
control:
-
automatic control
-
Weight:
-
about 18 T
-
Power(W):
-
55 kw
-
Certification:
-
ISO SGS CE
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Jucai
-
Voltage:
-
As your local need
-
Dimension(L*W*H):
-
6300*1500*2440mm
-
Warranty:
-
Within one year
-
Weight (KG):
-
7600 kg
-
Type:
-
Rubber Calender
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
roller:
-
cold hard cast iron
-
transmisson system:
-
roller ball bearing
-
gearbox:
-
hardened teeth gearbox
-
control:
-
automatic control
-
Weight:
-
about 18 T
-
Power(W):
-
55 kw
-
Certification:
-
ISO SGS CE
Product Description
Product Application
Main Features
|
Model
|
XY-230*630
|
XY-252*720
|
XY-360*1120
|
|
roller diameter
|
230
|
252
|
360
|
|
roller working length
|
630
|
720
|
1120
|
|
roller ratio
|
1:1:1/1:1.2:1
|
1:1:1
|
1:1:1
|
|
middle roll linear speed
|
0.8-8 M/MIN
|
2-15.9
|
3-20
|
|
Adjusting nip range
|
0-7
|
0-10
|
0-10
|
|
Min calendering thickness
|
0.2MM
|
0.2MM
|
O.2MM
|
|
calender product width
|
500
|
550
|
920MM
|
|
motor
|
7.5 KW
|
22 KW
|
45KW
|
|
machine weight
|
about 3 t
|
about 5.5 t
|
about 14 t
|
|
Model
|
XY-400*1200
|
XY-450*1400
|
XY-610*1730
|
|
roller diameter
|
400
|
450
|
610
|
|
roller working length
|
1200
|
1400
|
1730
|
|
roller ratio
|
1:1:1
|
1:1:1
|
1:1:1
|
|
middle roll linear speed
|
3-26.39
|
2.62-26.62
|
5.4-54
|
|
Adjusting nip range
|
0-10
|
0-10
|
0-20
|
|
Min calendering thickness
|
0.2
|
0.2
|
0.15
|
|
calender product width
|
1200
|
1250
|
1500
|
|
motor
|
55
|
75
|
160
|
|
machine weight
|
about 18t
|
about 21 t
|
about 43t
|
