Quick Details
-
Mold Height(mm):
-
400 - 900 mm
-
Ejector Stroke(mm):
-
260 mm
-
Ejector Force(kN):
-
175 kN
-
Theoretical Shot Volume(cm³):
-
2673 cm³
-
Injection Rate (g/s):
-
531 g/s
-
Injection Weight (g):
-
2430 g
-
Screw Speed (rpm):
-
0 - 130 rpm
-
Screw diameter (mm):
-
90 mm
-
Screw L/D Ratio:
-
22
-
Distance between Tie Bars:
-
910x910 mm
-
Weight (KG):
-
36000 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
920 mm
-
Model Number:
-
FHG650
-
Brand Name:
-
FUHONG
-
Power (kW):
-
67 kW
-
Screw Diameter:
-
80mm-110mm
-
Injection pressure:
-
118mpa-224mpa
-
Space between tie-bars:
-
910mm*910mm
-
Mould thickness:
-
400mm-900mm
-
Ejector stroke:
-
260mm
-
Ejector force:
-
175kn
-
Heating power:
-
46kw
-
Machine dimension(L*W*H):
-
9.9m*2.50m*3.00m
-
Machine weight:
-
36ton
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
910mm
-
Distance between Tie Bars(Height)(mm):
-
910mm
-
Plasticizing Capacity(g/s):
-
531
-
Mold Height(mm):
-
400 - 900 mm
-
Ejector Stroke(mm):
-
260 mm
-
Ejector Force(kN):
-
175 kN
-
Theoretical Shot Volume(cm³):
-
2673 cm³
-
Injection Rate (g/s):
-
531 g/s
-
Injection Weight (g):
-
2430 g
-
Screw Speed (rpm):
-
0 - 130 rpm
-
Screw diameter (mm):
-
90 mm
-
Screw L/D Ratio:
-
22
-
Distance between Tie Bars:
-
910x910 mm
-
Weight (KG):
-
36000 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
920 mm
-
Model Number:
-
FHG650
-
Brand Name:
-
FUHONG
-
Power (kW):
-
67 kW
-
Screw Diameter:
-
80mm-110mm
-
Injection pressure:
-
118mpa-224mpa
-
Space between tie-bars:
-
910mm*910mm
-
Mould thickness:
-
400mm-900mm
-
Ejector stroke:
-
260mm
-
Ejector force:
-
175kn
-
Heating power:
-
46kw
-
Machine dimension(L*W*H):
-
9.9m*2.50m*3.00m
-
Machine weight:
-
36ton
