Quick Details
-
Optical Resolution:
-
4mil
-
Scan Speed:
-
100 Scans/sec
-
Brand Name:
-
Xincode
-
Place of Origin:
-
Guangdong, China
-
Communication:
-
USB(KBW/COM) Blue tooth 2.4GHz RF wireless(USB dongle)
-
Transmission Distance:
-
Blue tooth-50M 2.4GHz 100M open air
-
Decoding Capability:
-
Reads Standard 1D
-
Battery:
-
450mAH continuously work 10hours,charge time 3-4H
-
Memory Size:
-
1.5m fall to cement
-
Internal Battery::
-
16MB store 10K barcodes
-
Indication:
-
Buzzer & LED
-
Material:
-
ABS+TPR
-
waterproof level:
-
IP41
Quick Details
-
Type:
-
Barcode Scanner
-
Scan Element Type:
-
CMOS
-
Max Paper Size:
-
A4
-
Optical Resolution:
-
4mil
-
Scan Speed:
-
100 Scans/sec
-
Brand Name:
-
Xincode
-
Place of Origin:
-
Guangdong, China
-
Communication:
-
USB(KBW/COM) Blue tooth 2.4GHz RF wireless(USB dongle)
-
Transmission Distance:
-
Blue tooth-50M 2.4GHz 100M open air
-
Decoding Capability:
-
Reads Standard 1D
-
Battery:
-
450mAH continuously work 10hours,charge time 3-4H
-
Memory Size:
-
1.5m fall to cement
-
Internal Battery::
-
16MB store 10K barcodes
-
Indication:
-
Buzzer & LED
-
Material:
-
ABS+TPR
-
waterproof level:
-
IP41
Technical Parameter
| Technical Specification | ||
| Product | Model Number | GT-S101 |
|
Reading
performance |
Image Sensor | CMOS 640*480 30fps |
| Resolution | 4mil(CMOS, can customize 3mil) | |
| Decoding capacity | Support paper and screen barcodes | |
| 2D: QR, Micro QR, PDF417, Micro PDF417, DataMatrix , AZTEC etc | ||
|
1D: Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar,
Interleaved 2 of 5, ITF-6, ITF-14, ISBN, Code 93, UCC/EAN-128, GS1 Databar, Matrix 2 of 5, Code 11, Industrial 2 of 5, Standard 2 of 5, Plessey, MSI-Plessey etc. |
||
| Light Source | 625±10nm white LED | |
| Scan Angle | Rotation360°,tilt±55°,skew±55° | |
| Min Contrast | 20% | |
| Typical DOF |
EAN13(13mul) 50 -260mm Code39(10mil) 35 -205mm
FDF417(10mil) 50 - 215mm Data Matrix(10mil) 50 - 160mm QR Code(15mil) 50 - 210mm Performance may be impacted by bar code quality and environmental conditions |
|
|
Mechanical
and electrical |
Communication | USB(KBW/COM) Blue tooth 2.4GHz RF wireless(USB dongle) |
| Blue tooth Protocol | Blue tooth HID,SPP,BLE | |
| Transmission Distance | Blue tooth—50M 2.4GHz 100M open air | |
| Working Voltage | DC 5±10%VDC | |
| Current & Power | 210mA(working) 7mA(standby) 3uA(sleep) | |
| Battery | 450mAH continuously work 10hours,charge time 3-4H | |
| Memory Size | 16MB store 10K barcodes | |
| Dimensions | 85*30*18mm | |
| Weight | 38g cable length 0.9M | |
| Indication | Buzzer & LED | |
| Material | ABS+TPR | |
|
Environment
Request |
Working Tem | -20~55℃ |
| Storage Tem | -40~80℃ | |
| Humidity | 5%-95%(Non-condensing) | |
| Light Immunity | 0~100,000Lux | |
| Drop Test | 1.5M | |
| waterproof level | IP41 |
