Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
DTC
-
Model Number:
-
fused silica glass sheet
-
Product Name:
-
fused silica glass sheet
-
Material:
-
fused silica
-
Color:
-
Transparent
-
Size:
-
Customer's Requirement
-
Surface quality:
-
40/20 60/40 80/50
-
Purity:
-
99.95%silica
-
MOQ:
-
1 Piece
-
Package:
-
Carton
-
Feature:
-
High Temperature Resistant
Quick Details
-
Type:
-
Clear Quartz Plate
-
Application:
-
Optics
-
Thickness:
-
1-50MM
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
DTC
-
Model Number:
-
fused silica glass sheet
-
Product Name:
-
fused silica glass sheet
-
Material:
-
fused silica
-
Color:
-
Transparent
-
Size:
-
Customer's Requirement
-
Surface quality:
-
40/20 60/40 80/50
-
Purity:
-
99.95%silica
-
MOQ:
-
1 Piece
-
Package:
-
Carton
-
Feature:
-
High Temperature Resistant
Factory price jgs1 fused silica crucible cube blank rods plate glass sheet
Product Description
| Quartz Glass Tube Tubing Hardeness | 5.5-6.5 Mohs' Scal 570 KHN 100 |
| Design Tensile Strength | 4.8X107 PA (N/mm2) (7000psi) |
| Design Compressive Strength | >1.1X109 PA (160, 000 psi) |
| Bulk Modulus | 3.7X1010 PA (5.3X106psi) |
| Rigidity Modulus | 3.1X1010 PA (4.5X106psi) |
| Young's Modulus | 7.2X10-10 PA (10.5X106 psi) |
| Poisson's Ratio | 0.17 |
| Coefficient of Thermal Expansion | 5.5X10-7cm/cm. °C (20°C-30°C) |
| Thermal Conductivity | 1.4 W/m. °C |
| Specific Heat | 670J/kg. °C |
| Softerning Point | 1683°C |
| Annealing Point | 1215°C |
| Strain Point | 1120°C |
| Electrical Receptivity | 7X107 ohm. Cm (350°C) |
| Velocity of Sound-Shear Wave | 3.75X103 m/s |
| Velocity of Sound/ Compression Wave | 5.9X103 m/s |
| Sonic Attenuation | <11dB/m MHz |
| Chemical Stability (except hydrofuoric) | High resistance to water and acids |
|
Dielectric Properties (20°C and 1MHz)
Constant Strength Loss Factor Dissipation Factor |
3.75 5X107 V/M Less than 4X10-4 Less than 1X10-4 |
Detailed Images
