Quick Details
-
Product name:
-
Best Quality Double Acting The Hydraulic Oil Cylinder Jack Jack Jack
-
Model:
-
KET-RR-756
-
Capacity:
-
75 T
-
Max. Working Pressure:
-
70MPa
-
Closed Height:
-
347 mm
-
Stroke:
-
156 mm
-
Effective Area:
-
102.7 cm2
-
Oil Capacity:
-
1602 cm3
-
Outside Diameter:
-
146 mm
-
Weight:
-
42 kg
Quick Details
-
Core Components:
-
Cylinder
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
KIET or OEM
-
Product name:
-
Best Quality Double Acting The Hydraulic Oil Cylinder Jack Jack Jack
-
Model:
-
KET-RR-756
-
Capacity:
-
75 T
-
Max. Working Pressure:
-
70MPa
-
Closed Height:
-
347 mm
-
Stroke:
-
156 mm
-
Effective Area:
-
102.7 cm2
-
Oil Capacity:
-
1602 cm3
-
Outside Diameter:
-
146 mm
-
Weight:
-
42 kg
Enerpac Telescopic Spring Return Double Acting Hydraulic Cylinder Jack 150ton For Press
Product Description
Photos:
Features:
Parameters:
| Model |
Capacity
(T) |
Stroke (mm) |
Effective area
(cm 2 ) |
Oil capacity
(cm 3 ) |
Closed Height
(mm) |
Weight (kg) | ||||
| push | pull | push | pull | |||||||
| KET-RR-1010 | 10 | 254 | 14.4 | 5.2 | 366 | 132 | 409 | 663 | 73 | 13 |
| KET-RR-1012 | 10 | 305 | 14.4 | 5.2 | 439 | 159 | 457 | 762 | 73 | 14 |
| KET-RR-308 | 30 | 210 | 42 | 19.4 | 882 | 407 | 387 | 596 | 102 | 18 |
| KET-RR-3014 | 30 | 368 | 42 | 19.4 | 1546 | 714 | 549 | 917 | 102 | 29 |
| KET-RR-506 | 50 | 156 | 71.4 | 21.9 | 1114 | 342 | 331 | 487 | 127 | 30 |
| KET-RR-5013 | 50 | 334 | 71.4 | 21.9 | 2385 | 731 | 509 | 843 | 127 | 52 |
| KET-RR-756 | 75 | 156 | 102.7 | 31.6 | 1602 | 493 | 347 | 503 | 146 | 42 |
| KET-RR-7513 | 75 | 334 | 102.7 | 31.6 | 3430 | 1055 | 525 | 858 | 146 | 68 |
| KET-RR-1006 | 100 | 168 | 133.2 | 61.9 | 2238 | 1040 | 357 | 525 | 178 | 61 |
| KET-RR-10013 | 100 | 334 | 133.2 | 61.9 | 4449 | 2057 | 524 | 867 | 178 | 93 |
| KET-RR-10018 | 100 | 461 | 133.2 | 61.9 | 6141 | 2854 | 687 | 1147 | 178 | 118 |
| KET-RR-1502 | 150 | 57 | 198.1 | 95.5 | 1129 | 544 | 196 | 253 | 203 | 50 |
| KET-RR-1506 | 150 | 156 | 198.1 | 95.5 | 3090 | 1490 | 385 | 541 | 203 | 93 |
| KET-RR-15013 | 150 | 334 | 198.1 | 95.5 | 6617 | 3190 | 582 | 915 | 203 | 125 |
| KET-RR-15032 | 150 | 816 | 198.1 | 95.5 | 16165 | 7793 | 1116 | 1931 | 203 | 238 |
