Quick Details
-
Dimension(L*W*H):
-
60*1.4*4.5
-
Weight:
-
60000
-
Power (kW):
-
65
-
Product name:
-
Condom making machine
-
Machine length:
-
60m
-
Machine weight:
-
60T
-
Workshop:
-
80*4.5*5.7m
-
Capacity:
-
1 to 3t dry ballons
-
Workers:
-
5 to 7 persons
-
Power:
-
65kw
-
Type:
-
Automatic Condom Production Line
-
Function:
-
Multi-colors Products Making
-
Usage:
-
Produce Rubber Moulded Products
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
Yugong machinery
-
Voltage:
-
380V/220v
-
Dimension(L*W*H):
-
60*1.4*4.5
-
Weight:
-
60000
-
Power (kW):
-
65
-
Product name:
-
Condom making machine
-
Machine length:
-
60m
-
Machine weight:
-
60T
-
Workshop:
-
80*4.5*5.7m
-
Capacity:
-
1 to 3t dry ballons
-
Workers:
-
5 to 7 persons
-
Power:
-
65kw
-
Type:
-
Automatic Condom Production Line
-
Function:
-
Multi-colors Products Making
-
Usage:
-
Produce Rubber Moulded Products
Product Description
Automatic Latex Condom Making Machine
1. Automatic design completely according to the chemical capability of raw material and condom molding craft work, compact facility flow.
1. Automatic design completely according to the chemical capability of raw material and condom molding craft work, compact facility flow.
2. According to the theory of hot air moving up, the oven adopts tunnel drying way to reclaim the hot wind by circulating
mixture that gets the best effect at the minimum power.
3. Utilize the effective heating space and the hot-wind circulation theory to reduce the cost; multi PID intelligent controlled
temperature systems make the error cannot exceed ±5, even heated and good brightness.
4. High output, special union joint design, easy to replace mould, picks up the circular speed.
5. Automatic vibrant drip or uniform latex system makes glove excellent and uniform thickness. 6. Adopt the special fire-resistant chain; pick up yield speed, advanced output.
mixture that gets the best effect at the minimum power.
3. Utilize the effective heating space and the hot-wind circulation theory to reduce the cost; multi PID intelligent controlled
temperature systems make the error cannot exceed ±5, even heated and good brightness.
4. High output, special union joint design, easy to replace mould, picks up the circular speed.
5. Automatic vibrant drip or uniform latex system makes glove excellent and uniform thickness. 6. Adopt the special fire-resistant chain; pick up yield speed, advanced output.
Specification
Technical features of vertical dipping and vertical flap drying condom equipment:
1. Adopting advanced three-step impregnation process technology, advanced process layout and diversified process production adjustment. 2. The ammonia water swelling process is cancelled and the longer alkaline water tank design is changed to achieve the effect of swelling and leaching, which is environmentally friendly and economical. 3. The template is made of 304 stainless steel, the whole chain is driven by three hosts, and the frequency conversion speed control is used to make the equipment run smoothly. 4. The whole machine is ceiling made of stainless steel plate and sealed with plastic steel. 5. The equipment has been fully, effectively and reliably designed to prevent head bubbles, back flow, crooked necks, curling, pinholes, etc. 6. It can produce all kinds of ordinary and special-shaped condoms such as smooth, granular, threaded, and colorful condoms. 7. All rubber materials used in production are pressure conveyed by fully enclosed stainless steel pipelines. 8. Energy-saving design of the film drying structure, which consumes 19.5kg of standard coal per 10,000 condoms. 9. De-filming with clean water and continuous pickling to fully ensure the cleanliness of molds and equipment. 10. Mix powder on the machine, dehydrate, and directly dry after vulcanization, making the production operation more energy-saving and simpler.
1. Adopting advanced three-step impregnation process technology, advanced process layout and diversified process production adjustment. 2. The ammonia water swelling process is cancelled and the longer alkaline water tank design is changed to achieve the effect of swelling and leaching, which is environmentally friendly and economical. 3. The template is made of 304 stainless steel, the whole chain is driven by three hosts, and the frequency conversion speed control is used to make the equipment run smoothly. 4. The whole machine is ceiling made of stainless steel plate and sealed with plastic steel. 5. The equipment has been fully, effectively and reliably designed to prevent head bubbles, back flow, crooked necks, curling, pinholes, etc. 6. It can produce all kinds of ordinary and special-shaped condoms such as smooth, granular, threaded, and colorful condoms. 7. All rubber materials used in production are pressure conveyed by fully enclosed stainless steel pipelines. 8. Energy-saving design of the film drying structure, which consumes 19.5kg of standard coal per 10,000 condoms. 9. De-filming with clean water and continuous pickling to fully ensure the cleanliness of molds and equipment. 10. Mix powder on the machine, dehydrate, and directly dry after vulcanization, making the production operation more energy-saving and simpler.
|
Machine Length
|
60M
|
80M
|
100M
|
120M
|
|
Container
|
6PCS
|
8PCS
|
10PCS
|
12PCS
|
|
Production capacity
|
Dry type 1T
|
Dry type 2T
|
Dry type 2.5T
|
Dry type 3T
|
|
Power
|
65KW
|
75KW
|
90KW
|
100KW
|
|
Chain
|
240M
|
320M
|
400M
|
480M
|
