Pneumatic manipulator machine swing arm robot single and double
Pneumatic manipulator machine swing arm robot single and double
Pneumatic manipulator machine swing arm robot single and double
Pneumatic manipulator machine swing arm robot single and double
Pneumatic manipulator machine swing arm robot single and double
Pneumatic manipulator machine swing arm robot single and double
Pneumatic manipulator machine swing arm robot single and double
Pneumatic manipulator machine swing arm robot single and double

Pneumatic manipulator machine swing arm robot single and double

FOB Reference Price: Get Latest Price
≥1 Sets
US $1100
Free Inquiry
Customized Request
Contact us For product pricing, customization, or other inquiries:
Contact Us
  • Product Details
  • {{item.text}}

Quick Details

Horizonal Travel(mm):
75---200
Place of Origin:
Guangdong, China
Brand Name:
NSTE
Model Number:
350V----950WV
Weight:
30--53
Dimension(L*W*H):
Customised
Power:
220V--950V
After-sales Service Provided:
Engineers available to service machinery overseas
Color:
write
Product name:
machine swing arm robot single and double
Certification:
SGS , iso

Quick Details

Warranty:
1 Year
Elevation Speed:
set by the customer need
Vertical Travel(mm):
350---950
Horizonal Travel(mm):
75---200
Place of Origin:
Guangdong, China
Brand Name:
NSTE
Model Number:
350V----950WV
Weight:
30--53
Dimension(L*W*H):
Customised
Power:
220V--950V
After-sales Service Provided:
Engineers available to service machinery overseas
Color:
write
Product name:
machine swing arm robot single and double
Certification:
SGS , iso
Description

General Specification

power source
power capacity
working pressure
max.allowed pressure
driven system
control system
1or3ØAC220V±10V

0.2
5kgf/cm2
8kgf/cm2

pneumatic

NST-X1
50/60HZ
0.49Mpa
0.8Mpa


Main Specification

model
350V
450V
550V/WV
650V/WV
750WV
850WV
950WV
Recommended L.M.M(ton)
15-30
30-60
50-100
50-150
150-200
200-280
200-280
vertical stroke (mm)
350
450
550
650
750
850
950
crosswise stroke (mm)

75

120

200
swing angle (degree)

60-90
take out time (sec)
0.6
0.7
0.8
0.9
1
1.2
1.4
max loading (kg)

1.5

2
all cycle time (sec)

3

3.5

4/4.2

4.2-4.4

4.8

5.2

6
air consumption (NI/cycle)

8.5

10

11.5/10.5

13/12

13

14.5

15.5
net weight (kg)
30
31
35-47
36-48
49
52
53
