Quick Details
-
Brand Name:
-
AMTRUE
-
Model Number:
-
ATP1220-08CBR
-
Output Frequency:
-
50-60hz
-
Output Current:
-
20AMP
-
Input Voltage:
-
220V
-
output:
-
8ways/channel/cameras
-
output power:
-
240W
-
protection:
-
over-voltage/over-current/short circuit protection
-
Case material:
-
iron/metal
-
Size(L*W*H):
-
395*285*165mm
-
Certificate:
-
CE,RoHs
-
OEM Accepted:
-
Yes
-
MOQ:
-
1 piece
-
Application:
-
cctv camera/access control/security equipment
Quick Details
-
Output Power:
-
201 - 300w
-
Output Voltage:
-
DC 12V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
AMTRUE
-
Model Number:
-
ATP1220-08CBR
-
Output Frequency:
-
50-60hz
-
Output Current:
-
20AMP
-
Input Voltage:
-
220V
-
output:
-
8ways/channel/cameras
-
output power:
-
240W
-
protection:
-
over-voltage/over-current/short circuit protection
-
Case material:
-
iron/metal
-
Size(L*W*H):
-
395*285*165mm
-
Certificate:
-
CE,RoHs
-
OEM Accepted:
-
Yes
-
MOQ:
-
1 piece
-
Application:
-
cctv camera/access control/security equipment
| Power Supply | |
| Input Voltage: | AC 100-240V |
| Frequency range: | 50/60Hz |
| Output Voltage: | DC 12V 20A |
| Product Dimension: | 195*225*80mm |
| Conversion efficiency: | ≥ 80% |
| Ripple wave: | (mVp-p): <1% |
| Line Regulation: | ± 0.5% max |
| Load Regulation: | ± 1% max |
| Temperature coefficient: | ± 0.03% (0 ~ 50°C) |
| Start time: | ≤ 3s (240VAC input, io=100%) |
| Guard time: | ≥ 20ms (240VAC input, io=100%) |
| Working temperature: | -20°C ~ 60°C |
| Storage temperature: | -30°C ~ 85°C |
| Humidity: | 0% ~ 95% RH |
| Setup, rise, hold up time: | 800ms, 50ms, 10ms/150V 300ms, 50ms, 80ms/230v |
| Vibration: | 10 ~ 500Hz, 2G 10min,/1 cycle. Period for 60min, Each axes |
| Withstand voltage: | I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC |
| Isolation resistance: | I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC |
| Overload Protection: | 105 ~ 150% rated output power, Auto recovery |
| Over Voltage Protection: | >115% ~ 135% rated output voltage |
| Warranty: | One Year |
