Quick Details
-
Mold Height(mm):
-
200 - 530 mm
-
Ejector Stroke(mm):
-
165 mm
-
Ejector Force(kN):
-
70 kN
-
Theoretical Shot Volume(cm³):
-
593 cm³
-
Injection Rate (g/s):
-
179 g/s
-
Injection Weight (g):
-
534 g
-
Screw Speed (rpm):
-
1 - 180 rpm
-
Screw diameter (mm):
-
55 mm
-
Screw L/D Ratio:
-
20
-
Distance between Tie Bars:
-
530*510
-
Weight (KG):
-
7000 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
490 mm
-
Model Number:
-
HJF240
-
Brand Name:
-
HAIJIA
-
Power (kW):
-
18.5 kW
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
-
Opening Stroke:
-
450mm
-
After-sales Service Provided:
-
Overseas third-party support available
-
Plastic injection moulding machine:
-
injection molding machine
-
Origin:
-
China
-
Clamping Force10000 (kN):
-
kN
-
Marketing Type:
-
New Product 2021
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
530mm
-
Distance between Tie Bars(Height)(mm):
-
510mm
-
Plasticizing Capacity(g/s):
-
179
-
Mold Height(mm):
-
200 - 530 mm
-
Ejector Stroke(mm):
-
165 mm
-
Ejector Force(kN):
-
70 kN
-
Theoretical Shot Volume(cm³):
-
593 cm³
-
Injection Rate (g/s):
-
179 g/s
-
Injection Weight (g):
-
534 g
-
Screw Speed (rpm):
-
1 - 180 rpm
-
Screw diameter (mm):
-
55 mm
-
Screw L/D Ratio:
-
20
-
Distance between Tie Bars:
-
530*510
-
Weight (KG):
-
7000 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
490 mm
-
Model Number:
-
HJF240
-
Brand Name:
-
HAIJIA
-
Power (kW):
-
18.5 kW
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
-
Opening Stroke:
-
450mm
-
After-sales Service Provided:
-
Overseas third-party support available
-
Plastic injection moulding machine:
-
injection molding machine
-
Origin:
-
China
-
Clamping Force10000 (kN):
-
kN
-
Marketing Type:
-
New Product 2021
