Quick Details
-
Injection Rate (g/s):
-
109 g/s
-
Injection Weight (g):
-
176 g
-
Screw diameter (mm):
-
42 mm
-
Weight (KG):
-
2300
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
250 mm
-
Model Number:
-
FT-600KS
-
Brand Name:
-
plastic injection molding machine
-
Power (kW):
-
7.5 kW
-
Name:
-
micro small mini plastic injection molding machine manufacturer
-
Certification:
-
CE
Quick Details
-
Ejector Stroke(mm):
-
65 mm
-
Ejector Force(kN):
-
2 kN
-
Theoretical Shot Volume(cm³):
-
194 cm³
-
Injection Rate (g/s):
-
109 g/s
-
Injection Weight (g):
-
176 g
-
Screw diameter (mm):
-
42 mm
-
Weight (KG):
-
2300
-
Place of Origin:
-
Guangdong, China
-
Open Stroke(mm):
-
250 mm
-
Model Number:
-
FT-600KS
-
Brand Name:
-
plastic injection molding machine
-
Power (kW):
-
7.5 kW
-
Name:
-
micro small mini plastic injection molding machine manufacturer
-
Certification:
-
CE
| INJECTION UNIT | Screw Diameter | mm | φ32 | φ36 | φ42 |
| Maximum Injection Pressure | Bar | 2051 | 1620 | 1190 | |
| Theoretical Shot Volume | cm 3 | 113 | 143 | 194 | |
| Maximum Shot Weight(PS) | g | 104 | 132 | 179 | |
| oz | 3.7 | 4.6 | 6.3 | ||
| Injection Rate | cm 3 /sec | 63 | 80 | 109 | |
| CLAMPING UNIT | Clamping Force | ton | 60 | ||
| Top Platen Size | mm | 610×460 | |||
| Slide Table Size | mm | 450×490 | |||
| Slide Stroke | mm | 500 | |||
| Mold Size | mm | 460×310 | |||
| Minimum Mold Thickness | mm | 200/300 | |||
| Opening Stroke | mm | 250 | |||
| Open Daylight | mm | 450/550 | |||
| Ejector Force | ton | 2 | |||
| Ejector Stroke | mm | 65 | |||
| OTHERS | Hydraulic System Pressure | Bar | 140 | ||
| Oil Tank Volume | L | 245 | |||
| Electric Power | hp(kW) | 10(7.5) | |||
| Barrel Heating Power | kW | 5.55 | |||
| Total Wattage | kW | 13.05 | |||
| Machine Dimensions(approx.) | m | 2.2×1.1×3.0 | |||
| Machine Weight(approx.) | ton | 2.3 | |||
