Quick Details
-
Dimension(L*W*H):
-
870X667X790mm
-
Weight:
-
229KG
-
Warranty:
-
1year/1500hours
-
Certification:
-
ISO9001:2008
-
Brand:
-
MHM
-
Engine brand:
-
Isuzu
-
ATS/AMF:
-
Optional
-
Silent Type:
-
Optional
-
Advantage:
-
small volume,good quality,lowest price
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
MHM
-
Model Number:
-
4JB1
-
Dimension(L*W*H):
-
870X667X790mm
-
Weight:
-
229KG
-
Warranty:
-
1year/1500hours
-
Certification:
-
ISO9001:2008
-
Brand:
-
MHM
-
Engine brand:
-
Isuzu
-
ATS/AMF:
-
Optional
-
Silent Type:
-
Optional
-
Advantage:
-
small volume,good quality,lowest price
| Model of Diesel Generator | VI24GF |
| Prime /Max Output(kw) | 24/26.4 |
| Rated voltage (V) | 220/380V |
| Rated frequency (Hz) | 50HZ |
| Type | open type |
| Model of Diesel Engine | Isuzu 4JB1T |
| Rated Output | 28KW |
| Rated Speed (r/min) | 1500rpm |
| Starting Method | 12V DC Electrical motor |
| Governing Method | Electric governing |
| Intake Method | Turbocharged |
| Cylinders | 4.L |
| Type | closed water cooling,in-line,4 stroke,humid liner,direct injection |
| Bore/stroke | 93/102mm |
| Displacement | 2.771L |
| Fuel consumption(g/kW.h) | 6.5L/H |
| Model of Alternator | JSA184L9 |
| Rated Power(KW) | 25KW |
| Rated Frequency | 50HZ/1500rpm |
| Power Factor(cosφ) | 0.8(lag) |
| Excitation | Brushless |
| Connection | 3phase-4wire |
| Control System | low/over speed, Battery charger fail;Urgent shut down; Low oil pressure; High water temperature; Starting failure;Loss of speed signal; and so on. |
| Delivery Time | about 20 working days after received 30%deposit |
