Quick Details
-
Brand Name:
-
SMARTS
-
Model Number:
-
SMT-012-100VW
-
Output Frequency:
-
47-63Hz
-
Output Current:
-
8.33A
-
IP rate:
-
IP67
-
outer case:
-
aluminium housing
-
working mode:
-
constant voltage type
-
size:
-
200*68*53mm
-
unit weight:
-
900g
-
efficiency:
-
>83%
-
energy transfer:
-
AC-DC
-
certificate:
-
CE, ROHS approval
-
warranty:
-
2 year warranty
-
item:
-
dc12 v transformer
Quick Details
-
Input Voltage:
-
100-265vAC
-
Output Voltage:
-
12V
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
SMARTS
-
Model Number:
-
SMT-012-100VW
-
Output Frequency:
-
47-63Hz
-
Output Current:
-
8.33A
-
IP rate:
-
IP67
-
outer case:
-
aluminium housing
-
working mode:
-
constant voltage type
-
size:
-
200*68*53mm
-
unit weight:
-
900g
-
efficiency:
-
>83%
-
energy transfer:
-
AC-DC
-
certificate:
-
CE, ROHS approval
-
warranty:
-
2 year warranty
-
item:
-
dc12 v transformer
110 volt ac 12/24 v dc transformer
Product Description
| Label |
|
| Description |
|
| SPECIFICAION | |||
| MODEL | SMT-012-100VW | SMT-024-100VW | |
| OUTPUT | DC VOLTAGE | 12V | 24V |
| RATED CURRENT | 8.33A | 4.16A | |
| CURRENT RANGE | 0~8.33A | 0~4.16A | |
| RATED POWER | 100W | 100W | |
| RIPPLE&NOISE(max) | 150mV | 150mV | |
| VOLTAGE TOLERANCE | ±0.5V | ±0.5V | |
| SETUP RISE TIME | 80ms/110V,220VAC | ||
| HOLD UP TIME(Typ.) | 60ms/110V,220VAC | ||
| INPUT | VOLTAGE RANGE | 100~265VAC | |
| FREQUENCY RANGE | 50~60Hz | ||
| POWER FACTOR(Typ.) | |||
| EFFICIENCY(Typ.) | >83% | ||
| AC CURRENT(Typ.) | 0.92A/110VAC, 0.86A/220VAC | ||
| INRUSH CURRENT (Typ.) | COLD START 50A/110VAC, 220VAC | ||
| PROTECTION | Short circuit | Protection type:recovers automatically after condition is removed | |
| Overload | overload protected@145-160% above peak rating | ||
| Over temperature | Protection type:Shut down o/p voltage,re-power on to removed | ||
| ENVIRONMENT | WORKING TEMP. | -30~+50℃ (Refer to output load derating curve) | |
| WORKING HUMIDITY | 20~99% RH non-condensing(Waterproof IP67) | ||
| STORAGE TEMP.,HUMIDITY | -40~+80℃,10~99%RH | ||
| SAFETY&EMC | SAFETY STANDARDS | CE Mark(LVD) | |
| WITHSTAND VOLTAGE | I/P-O/P:1.5KVAC IP-GND:1.5KVAC | ||
| EMC Test Standards | EN55015:2006;EN61547:1995+2000;EN61000-3-2:2006 | ||
| EN61000-3-3:1995+A2:2005;EN61346-1:2001;EN61347-2-13:2006 | |||
