Quick Details
-
Model Number:
-
FY-M01
-
Theory::
-
Resistance Sensor
-
Output::
-
Analog Sensor, 0.5 ~ 4.5VDC
-
Pressure range::
-
0 ~2bar/5bar/8Bar/10Bar
-
Power supply:
-
5.0 ± 0.5VDC
-
Pressure port::
-
G1/4 G1/2 By customized
-
Measures Temp:
-
-30℃-85℃
-
Medium:
-
Air, water, oil
-
Name:
-
cheap 0-5v engine oil pressure sensor
Quick Details
-
Warranty:
-
1 YEAR
-
Place of Origin:
-
Shaanxi, China
-
Brand Name:
-
FENGYU
-
Model Number:
-
FY-M01
-
Theory::
-
Resistance Sensor
-
Output::
-
Analog Sensor, 0.5 ~ 4.5VDC
-
Pressure range::
-
0 ~2bar/5bar/8Bar/10Bar
-
Power supply:
-
5.0 ± 0.5VDC
-
Pressure port::
-
G1/4 G1/2 By customized
-
Measures Temp:
-
-30℃-85℃
-
Medium:
-
Air, water, oil
-
Name:
-
cheap 0-5v engine oil pressure sensor
Explosion Proof LNG LPG CNG Gas Pressure Sensor
| Model |
Explosion Proof LNG LPG CNG Gas Pressure Sensor |
|
| Pressure range | 0 ~2bar/5bar/8Bar/10Bar/12Bar/25Bar. | Other range 0~3bar……100Bar(price is higher) |
| Body materials: | Carbon steel alloy or Stainless steel | |
| Overload | 150% | |
| Accuracy | ≤1.0%F.S.(Typical) | |
| Max Error: | ± 1.5 %FS~±3%F.S. (including 0 ~ 90 ℃ temperature error) | |
| Working Temp | 30℃~105 ℃ | |
| Storage Temp | 40℃~85℃ | |
| Supply voltage | 5.0 ± 0.5VDC | |
| Output voltage | 0.5 ~ 4.5VDC | |
| Pressure cycle life | 500,000 | |
| Protection | IP65 | |
| Pressure port | G1/4 G1/2 By customized (price is higher) | |
| Measures media | Air, water, oil and other non-corrosive, non-solvent medium | |
| Vibration | 10Hz,3mm/ one hour | |
| Cable | Red wire - +5VDC, Black(or white)-GND, Blue(or green)-V out | |
| Connector | 1pin-5VDC,2pin-null,3pin-Vout,4pin-GND(Acquiescence type:C2521HF-4P) | |
| Certificate approving: | ROSH and CE Certificate. | |
| Remarks: | Special applications request ,can custom by order | |
