Quick Details
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT, jpg
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
31.4*19.6*9.8inch
-
Weight (KG):
-
38 KG
-
laser power:
-
40W
-
laser type:
-
Hermetic CO2 glass tube
-
data transfer interface:
-
USB
-
cooling way:
-
water cooling
-
software:
-
corellaser+coreldraw or laserdrw
-
cutting thickness:
-
0-10mm(depends on different material)
-
Power supply:
-
220V/110V±10%
-
Function:
-
engraving and cutting
-
wave length:
-
10.6um
-
Name:
-
rubber stamp making machine
Quick Details
-
Engraving Area:
-
30*20cm
-
Laser Type:
-
CO2
-
Engraving Speed:
-
0-350mm/s
-
Graphic Format Supported:
-
AI, BMP, Dst, Dwg, DXF, DXP, LAS, PLT, jpg
-
Place of Origin:
-
China
-
Dimension(L*W*H):
-
31.4*19.6*9.8inch
-
Weight (KG):
-
38 KG
-
laser power:
-
40W
-
laser type:
-
Hermetic CO2 glass tube
-
data transfer interface:
-
USB
-
cooling way:
-
water cooling
-
software:
-
corellaser+coreldraw or laserdrw
-
cutting thickness:
-
0-10mm(depends on different material)
-
Power supply:
-
220V/110V±10%
-
Function:
-
engraving and cutting
-
wave length:
-
10.6um
-
Name:
-
rubber stamp making machine
High precision rubber stamp making machine co2 laser engraver
Applicable Materials
Various non-metal materials,such as rubber, acrylic, plexiglass, bowlder, crystal, wood, plastic, alumina,painted metal etc.
Applicable Industry
specification
|
Laser Power
|
40W/50W(CO2 glass tube) |
| Power Supply | AC220/110V±10% |
| Operating Temperature | 5°C-35°C ( water cooling to keep it) |
| Gross power | 500W |
| Max Engraving Area | 300x200(mm) |
| Working Speed | 0-350mm/s |
|
Package
|
double carton box or plyood case |
| controller | M2 |
| Software | Laserdrw/corellaser+coreldraw |
| compatiable Systerm | windows98/2000/xp/windows7/windows10 |
| Resolution Ratio | 1000dpi |
| date transfer | USB port |
| Cooling type | Water cooling |
| Warranty | One year |
|
Machine Dimension
|
810x500x250(mm) |
| Package Dimension | 940x620x400(mm) |
| Net Weight/Gross Weight | 25kg/38kg |
| Production Time | within 3 workdays after receive payment |
| Warranty | One year |
| Standard Accessories with the machine | Exhaust fan, water pump,smoke pipe, power line, water pipe,software CD, User manual, Dongle, USB line |
machine photos
Standard Accessories
- 1 x Exhaust Fan
- 1 x Venting Tube
- 1 x Water Pump
- 1 x USB Key & USB Cable
- 1 x CD with Software , maunal and video (laserdrw, corellaser , coreldrawsoftware all included in CD.)
- 1 x Manual
- 1 x power line
- 1 x adjust optical path paper
- 1 x silicone
-
