Quick Details
-
Application:
-
LANDSCAPE
-
Input Voltage(V):
-
AC85-265V/24V
-
Lamp Luminous Flux(lm):
-
100-110LM/W for white
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 40
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XING CAN
-
Model Number:
-
XC-DMD-E
-
Product name:
-
Under Ground Lights
-
Material:
-
Aluminim+glass
-
Color:
-
Red/yellow/blue/green/white/warm white/RGB
-
Type:
-
LED Undergroundlight
-
IP grade:
-
IP 67
-
Beam angle:
-
5°15°30°45°60°90°120°
Quick Details
-
Color Temperature(CCT):
-
2700-6500k
-
Warranty(Year):
-
3-Year
-
Lamp Body Material:
-
Aluminum
-
Application:
-
LANDSCAPE
-
Input Voltage(V):
-
AC85-265V/24V
-
Lamp Luminous Flux(lm):
-
100-110LM/W for white
-
CRI (Ra>):
-
80
-
Working Temperature(℃):
-
-20 - 40
-
Working Lifetime(Hour):
-
50000
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
XING CAN
-
Model Number:
-
XC-DMD-E
-
Product name:
-
Under Ground Lights
-
Material:
-
Aluminim+glass
-
Color:
-
Red/yellow/blue/green/white/warm white/RGB
-
Type:
-
LED Undergroundlight
-
IP grade:
-
IP 67
-
Beam angle:
-
5°15°30°45°60°90°120°
Product Description
| Model | XC-DMD-E | ||
| Power | Size:L*W*H(mm) | Hole-cutting Size | |
| 3W | 200*90*50 | 190*70mm | |
| 6W | 300*90*75 | 290*75*75mm | |
| 9W | 500*90*75 | 485*75*75mm | |
| 12W | 600*90*75 | 585*75*75mm | |
| 18W | 1000*90*75 | 985*75*75mm | |
| 24W | 1000*120*80 | 985*100*75mm | |
| 36W | 1000*120*80 | 985*100*80mm | |
| Voltage | AC85-265V/24V | ||
| Color | Red/yellow/blue/green/white/warm white/RGB | ||
| Luminous flux | 100-110LM/W for white | ||
| LED Type | Epistar | ||
| LED Driver | DONE | ||
| Material | Aluminim+glass | ||
| Beam angle | 5°15°30°45°60°90°120° | ||
| Power factor | >0.90 | ||
| CRI | >80 | ||
| IP Grade | IP67 | ||
| Lifetime | 50000hrs | ||
| Warranty | 3 years | ||
| Certification | CE&RoHS | ||
