Quick Details
-
Brand Name:
-
TONVA
-
Year:
-
2020(The company was founded in 1993)
-
Voltage:
-
380 V/3PH/50 Hz
-
Dimension(L*W*H):
-
9.5m*4.5m*6.8m
-
Hollow part volume:
-
500L,1000L,2000L
-
Screw diameter (mm):
-
140 mm mm
-
Screw Heating Power(kW):
-
55 kW
-
Extruder Motor Power(kW):
-
130 kW
-
Mold Platen Size(Width)(mm):
-
1900 mm mm
-
Mold Platen Size(Height)(mm):
-
2100 mm mm
-
Air Pressure(MPa):
-
0.8 MPa
-
Air Comsumption(m³/min):
-
3.0 m³/min
-
Die Head Heating Power(kW):
-
50 kW
-
Accumulator Capacity(L):
-
70 L
-
Power (kW):
-
279
-
Weight (T):
-
40
-
Product name:
-
water tank blow molding machine
-
Type:
-
Accumulator Die Head Machine
-
Use:
-
Large water tank/plastic table,floating,pontoon,boat etc.
-
Feature:
-
Advanced Technology
-
Production capacity:
-
400-460 kg/h
-
Advantages:
-
Easy Operation
-
Layer:
-
1-6 Layers
-
Material:
-
PE,PP,HDPE
-
Function:
-
Widely Used
-
Certification:
-
CE ISO
Quick Details
-
Clamping Force (kN):
-
1500
-
Output (kg/h):
-
460 kg/h
-
Place of Origin:
-
Zhejiang, China, Taizhou city
-
Brand Name:
-
TONVA
-
Year:
-
2020(The company was founded in 1993)
-
Voltage:
-
380 V/3PH/50 Hz
-
Dimension(L*W*H):
-
9.5m*4.5m*6.8m
-
Hollow part volume:
-
500L,1000L,2000L
-
Screw diameter (mm):
-
140 mm mm
-
Screw Heating Power(kW):
-
55 kW
-
Extruder Motor Power(kW):
-
130 kW
-
Mold Platen Size(Width)(mm):
-
1900 mm mm
-
Mold Platen Size(Height)(mm):
-
2100 mm mm
-
Air Pressure(MPa):
-
0.8 MPa
-
Air Comsumption(m³/min):
-
3.0 m³/min
-
Die Head Heating Power(kW):
-
50 kW
-
Accumulator Capacity(L):
-
70 L
-
Power (kW):
-
279
-
Weight (T):
-
40
-
Product name:
-
water tank blow molding machine
-
Type:
-
Accumulator Die Head Machine
-
Use:
-
Large water tank/plastic table,floating,pontoon,boat etc.
-
Feature:
-
Advanced Technology
-
Production capacity:
-
400-460 kg/h
-
Advantages:
-
Easy Operation
-
Layer:
-
1-6 Layers
-
Material:
-
PE,PP,HDPE
-
Function:
-
Widely Used
-
Certification:
-
CE ISO
Product Description
|
Type
|
Dimension(L*W*H)
|
Layer
|
Application
|
Support
|
|
TVA-
2000L
|
9.5mX4.5mX6.8m
|
1~6
|
Water tank,plastic table,chair,boat,pallet and pontoon etc.
|
Field installation, commissioning and training
|
Advantages
● Rich experienced
●Mould design
●Filter system
●Extrusion system
● About debugging
Mould
Customization
Certifications
Application
Packing & Delivery
