Quick Details
-
Brand Name:
-
6EP1334-3BA10
-
Model Number:
-
6EP1334-3BA10
-
Output Frequency:
-
50/60Hz
-
Output Current:
-
10A
-
serial:
-
6ep1334-3ba10
-
Product:
-
SITOP modular
-
Power supply, type:
-
24 V DC/ 10 A
-
Supply voltage: Note:
-
Set by means of selector switch on the device
-
series:
-
SITOP
Quick Details
-
Input Voltage:
-
AC120/230-500V, AC120/230-500V
-
Output Voltage:
-
DC24V
-
Place of Origin:
-
Romania
-
Brand Name:
-
6EP1334-3BA10
-
Model Number:
-
6EP1334-3BA10
-
Output Frequency:
-
50/60Hz
-
Output Current:
-
10A
-
serial:
-
6ep1334-3ba10
-
Product:
-
SITOP modular
-
Power supply, type:
-
24 V DC/ 10 A
-
Supply voltage: Note:
-
Set by means of selector switch on the device
-
series:
-
SITOP
Product Description
| Product | |
| Article Number (Market Facing Number) | 6EP1334-3BA10 |
| Product Description | SITOP PSU200M 10 A stabilized power supply input: 120/230-500 V AC output: 24 V DC/ 10 A *Ex approval no longer available* |
| Product family | 1- and 2-phase, 24 V DC |
| Output | |
| Output | Controlled, isolated DC voltage |
| Rated voltage Vout DC | 24 V |
| Total tolerance, static ± | 3 % |
| Static mains compensation, approx. | 0.1 % |
| Static load balancing, approx. | 0.1 % |
| Residual ripple peak-peak, max. | 50 mV |
| Spikes peak-peak, max. (bandwidth: 20 MHz) | 200 mV |
| Adjustment range | 24 … 28.8 V |
| Product feature / output voltage adjustable | Yes |
| Output voltage setting | via potentiometer |
| Status display | Green LED for 24 V OK |
| Signaling | via signaling module (6EP1961-3BA10) |
| On/off behavior | Overshoot of Vout approx. 3 % |
| Startup delay, max | 1s |
| Voltage rise, typ. | 50 ms |
| Rated current value Iout rated | 5 A |
| Current range | 0 … 5 A |
| delivered active power / typ. | 120 W |
| 5.5 A | |
| short-term overload current / at short-circuit during operation / typical | 15A |
| 25 ms | |
| Parallel switching for enhanced performance | Yes |
| Numbers of parallel switchable units for enhanced performance | 2 |
