Quick Details
-
Brand Name:
-
WINSTON/OEM
-
Model Number:
-
T-60D
-
Output Frequency:
-
50/60HZ
-
Output Current:
-
2.5A
-
Weight:
-
0.55KG
-
OEM/ODM:
-
Yes
-
EMC standards:
-
Design refer to GB9254,EN55022,class B
-
Usage:
-
Power tool,Office,Appliance/Kitchen Appliance,Industrial Equipment etc
Quick Details
-
Input Voltage:
-
220VAC,110VAC/220VAC
-
Output Voltage:
-
12V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
WINSTON/OEM
-
Model Number:
-
T-60D
-
Output Frequency:
-
50/60HZ
-
Output Current:
-
2.5A
-
Weight:
-
0.55KG
-
OEM/ODM:
-
Yes
-
EMC standards:
-
Design refer to GB9254,EN55022,class B
-
Usage:
-
Power tool,Office,Appliance/Kitchen Appliance,Industrial Equipment etc
Product Description
Technique parameter
| Type | Output | Error | Range | Efficiency |
| T-60A | 5V,0-5A | ±2% | 50mV | 72% |
| 12V,0-2.5A | ±6% | 100mV | ||
| -5V,0-0.5A | ±6% | 100mV | ||
| T-60B | 5V,0-5A | ±2% | 100mV | 72% |
| 12V,0-2.5A | ±6% | 120mV | ||
| -12V,0-0.5A | ±6% | 120mV | ||
| T-60C | 5V,0-5A | ±2% | 100mV | 72% |
| 15V,0-2A | ±6% | 120mV | ||
| -15V,0-0.5A | ±6% | 120mV | ||
| T-60D | 5V,0.5-5A | ±2% | 80mV | 72% |
| 12V,0.2-2.5A | ±6% | 100mV | ||
| 24V,0.2-0.5A | ±6% | 100mV |
| AC Input voltage range | 88-264VAC 47-63HZ; 120-370VDC | |||
| Input current | 2A/115V 1A/230V | |||
| AC inrush current | Cold-start current 30A/115V 60A/230V | |||
| Leakage current | <3.5mA/240VAC | |||
| DC adjustable range | ±10% rated output voltage | |||
| Over load protection | 105-150% hiccup mode,auto-recovery | |||
| Over voltage protection | ||||
| Setup, rise ,hold up time | 300ms 50ms 80ms/230VAC | |||
| Withstand voltage | I/P-O/P:1.5KvAC 1minute | |||
| I/P-FG:1.5KvAC 1minute | ||||
| O/P-FG:0.5KvAC 1minute | ||||
| Working temperature | -10℃~+60℃,20%~90%RH | |||
| Weight/packing | 0.55KG,30pcs/16.5KG 34*32*24CM | |||
| Product's Size | 159*98*38mm | |||
| Note: | |||
| 1.The testing condition for the paramenter above is :230VAC input,rated load,25 ℃ 70% RH.Humidity. | |||
| 2.Error.include the setting error,line stability and load stability.(Note:5). | |||
| 3.Wave test:adopting "A12"double wire for 20MHz,and 0.1UF&47UF capacitor short-circuit for interrupting. | |||
| 4.Inlet voltage stability test:when is over load,the lowest voltage of inlet is up to the highest voltage. | |||
| 5.Load stability test:the load is from 0% to 100%. |
