Quick Details
-
Brand Name:
-
FangSheng/OEM
-
Model Number:
-
12V 15W IP67
-
Output Frequency:
-
50/60Hz
-
Output Current:
-
1.25A
-
Product size:
-
95*30*20mm
-
Weight:
-
106g
-
Warranty:
-
2 years
Quick Details
-
Input Voltage:
-
220V
-
Output Voltage:
-
12V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
FangSheng/OEM
-
Model Number:
-
12V 15W IP67
-
Output Frequency:
-
50/60Hz
-
Output Current:
-
1.25A
-
Product size:
-
95*30*20mm
-
Weight:
-
106g
-
Warranty:
-
2 years
Product Description
| Model | 12V 15W IP67 |
| Specification | 12V 1.25A 15W |
| DC output voltage | 12V |
| Output voltage error | ±5% |
| Rated output current | 1.25A |
| Output current rage | 0-1.25A |
| Wave and noise | 120mVp-p |
| Inlet stability | ±0.5% |
| Load stablity | ±1% |
| DC output power | 15W |
| Efficiency | 85% |
| Adjustable range for DC voltage | +10,-5% |
| AC input voltage range | 85-264VAC 47-63Hz |
| Input current | 0-1.25A |
| Leakage current | <3.5mA/240VAC |
| Overload proctection | 105%~150% Tpye pulsing hiccp shutdown Reset:auto recovery |
| Over-voltage protection | 115%~135% |
| High-temperature protection | 65℃ |
| Temperature coefficient | ±0.03%/°C(0~50%) |
| Setup rise hold up time | 800ms,50ms,10ms/115V 300ms,50ms,80ms/230VAC |
| Vibration | 10-500HZ,2G 10min,/1cycle,Period for 60min,Each axes |
| Withstand voltage | Input and output internal ,1.5KVAC,Input and enclosure,.5KVAC,Output and enclosure,0.5KVAC |
| Isolation resistance | Input and output internal,Input and enclosure,Output and enclosure,500VDC/100MΩ |
| Working temperature and humidity | -10°C~+60°C(Refer to output derating curve),20%~90%RH |
| Store temperature and humidity | -20°C~+85°C,10%~95%RH |
| Overall dimension(mm) | 95*30*20 |
| Weight(g) | 106 |
| Application | LED strip light,LED down light,led panel light, Outdoor etc.. |
Packaging & Shipping
White box for single item, 100 pieces per ourter carton. 11.5kg/ctn. 38*25.5*21cm. DHL/UPS/EMS/TNT/SEA Shipment
