Quick Details
-
Weight (KG):
-
21500 KG
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
Canada
-
After-sales Service Provided:
-
Online support
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
SHUIPO
-
Welding Mode:
-
MIG SAW
-
Weight (KG):
-
21500 KG
-
After Warranty Service:
-
Video technical support
-
Local Service Location:
-
Canada
-
After-sales Service Provided:
-
Online support
| a.Appearance of obverse welding side beautiful and uniform, excess weld metal is less than 1mm, the width deviation is less than 1 mm. | |||||||
|
b.100% weld penetration, appearance of obverse welding side beautiful and uniform, excess weld metal deviation is small.
|
|||||||
|
c Make sure not break the arc during the welding process.
|
|||||||
|
d Plate surface can't scratch.
|
|||||||
| e Ensure within 30 mm near the weld seam and the weld seam without oil, burr, rust and other defects. | |||||||
|
f The gap between two plates less than 1mm; Unfitness of butt joint is less than 10% of the plate thickness.
|
|||||||
| g Must add arc starting and arc stopping plate. |
| Effective Welding Length | 8000mm | ||||
| Welding Metal Base | Aluminium alloy | ||||
| Thickness of the Metal Base | |||||
| Welding process | Mig | ||||
| Arc control | The arc voltage automatic tracking system | ||||
|
Effect of the Welding
Seam |
One-Side is Welded; Two Sides are Shaped. (No need open groove) | ||||
| Way of Pressing the Work Piece | The Cylinder Keyboard Pressed | ||||
| Welding speed | 50-300mm/min | ||||
| Molding groove material | Stainless steel(double groove,Three sections of arc transition, groove depth is 2mm) | ||||
| Molding groove cooling type |
Water cooling |
||||
|
Travel speed (empty) |
Infinitely variable speeds(The adjusting range is 0 to 4000 mm/min) | ||||
| Welding torch quantity | 1 set | ||||
| Positioning device | 4 sets | ||||
| Electric feeding device | 4 sets | ||||
| Electric discharging device | 4 sets | ||||
|
Effect of the Welding
Seam |
One-Side is Welded; Two Sides are Shaped. |
||||
| Power voltage | AC380 50HZ | ||||
| Machine power | 30KW | ||||
