Quick Details
-
Brand Name:
-
Ganghua
-
Model Number:
-
GH-520
-
Product name:
-
Book Binding Machine
-
Binding speed:
-
1200-1700 cycles/hr
-
Max binding length:
-
520mm
-
Max Binding thickness:
-
22mm
-
Voltage:
-
220V/1ph/50Hz
-
Binding size:
-
Diameter:1/4"-7/8"
-
Function:
-
Binder notebook
-
Weight:
-
275KG
-
Brand:
-
Ganghua
-
Binding Thickness:
-
4.8mm-22mm
Quick Details
-
Type:
-
Wire Binding Machine
-
Power:
-
Electricity
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Ganghua
-
Model Number:
-
GH-520
-
Product name:
-
Book Binding Machine
-
Binding speed:
-
1200-1700 cycles/hr
-
Max binding length:
-
520mm
-
Max Binding thickness:
-
22mm
-
Voltage:
-
220V/1ph/50Hz
-
Binding size:
-
Diameter:1/4"-7/8"
-
Function:
-
Binder notebook
-
Weight:
-
275KG
-
Brand:
-
Ganghua
-
Binding Thickness:
-
4.8mm-22mm
| Feeding Mode | Manual |
| Handing of Double Wire |
Automatic
Cutting,Inserting, Closing & Conveying |
| Double Loop Wire Specifications |
Diameter:1/4"-
7/8"(Pitch:3:1, 2:1) |
| Max. Paper Width mm | 520 |
| Max. Binding Width mm | 507 |
| Min. Paper Length mm | 75 |
| Working Speed cycles/hr | 1200~1700 |
| Size of Worktable(WXD) mm | 660X300 |
| Power | 220V/1ph/50Hz |
| Air Compressor (not included) kw | 1.5 |
| Air Pressure bar | 6~8 |
| Machine Dimensions (LXWXH)mm | 1000X760X1230 |
| Net Weight kg | 271 |
|
Dimensions of Pay-Off Unit
(LXWXH) mm |
490X760X1230 |
| Net Weight kg | 54 |
