Quick Details
-
Application:
-
Hotel
-
Design Style:
-
Modern
-
Type:
-
fireproof board
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Wellyoung
-
Model Number:
-
WY150053
-
Color:
-
white& grey
-
Thickness:
-
18-20mm
-
Size:
-
1220*2440mm/1200*2400mm/1200* 3000mm
-
Fireproof:
-
A1 according to PN-EN13501-1+A1:2010
-
Certficate:
-
CE TUV
-
Other advantages:
-
eco-friendly,non-asbestos,strong
-
Fireproof board Matetial:
-
Fireproof MgO board/ Magnesium oxide board
-
Security:
-
Non-toxic, no asbestos, no formaldehyde
-
Features:
-
water/damp/moisture resistant
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
Others
-
Application:
-
Hotel
-
Design Style:
-
Modern
-
Type:
-
fireproof board
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Wellyoung
-
Model Number:
-
WY150053
-
Color:
-
white& grey
-
Thickness:
-
18-20mm
-
Size:
-
1220*2440mm/1200*2400mm/1200* 3000mm
-
Fireproof:
-
A1 according to PN-EN13501-1+A1:2010
-
Certficate:
-
CE TUV
-
Other advantages:
-
eco-friendly,non-asbestos,strong
-
Fireproof board Matetial:
-
Fireproof MgO board/ Magnesium oxide board
-
Security:
-
Non-toxic, no asbestos, no formaldehyde
-
Features:
-
water/damp/moisture resistant
Product Description
Production Flow
Specifications
| TEST ITEM | UNIT | TEST RESULT | |
| Bending Strength | Mpa | 6MM | Width: >18 |
| Length: >15 | |||
| 9MM&12MM-18MM | Width: >16 | ||
| Length: >13 | |||
| Water Absorption | % | <10% | |
| Thermal Contraction | % | <0.14(w/mk) (30 °C ) | |
| Density | g/cm 3 | 0.9-1.15 | |
| Freezing Resistance | After 25 Freezing cycles | No Delaminated | |
| Combustibility | - | Incombustible ( class A1 ) | |
| Fire Resistance Limit | Min | 2 Layers Mineral Wool:180 | |
| Thermal Conductivity | W/(m • k) | <0.12 | |
| Wall Average Acoustical Deduction Factor | dB | 2 Layers 50mm Mineral Wool: 44 | |
| Impact Strength | kg/C | :2.0 | |
| Water resistance | no condensation on the opposite side | ||
- Non-Toxic material safe to cut
- Resistance to fire, moisture, and wood boring insects
- Lightweight – easy to nail & screw
- ASTM & ANSI tested
- Less energy required to install
- Long lasting materials – reducing repair and replacement costs
- No silica-based Portland cement
- Post-consumer recycled content
- Gypsum-free,Asbesto-free
- Advanced Magnesium cement replaces ordinary Portland cement
- Solid construction – no laminations
| Item no. | Size(mm) | Weight(kg) | |
| 3048 | 1220x2440x3 | 10 | 1820 pcs |
| 4048 | 1220x2440x4 | 14 | 1350 pcs |
| 6048 | 1220x2440x6 | 18 | 1080 pcs |
| 8048 | 1220x2440x8 | 24 | 808 pcs |
| 10048 | 1220x2440x10 | 28 | 648 pcs |
| 12048 | 1220x2440x12 | 34 |
540 pcs
|
- Suspended ceilings – 6 mm
- Paneling of exterior walls, under bay space and balconies – 10 mm
- Lining of interior walls – 6 mm
- Construction of self-supporting wall structures and partitions – 10 mm
- Floors – 16-20 mm
- Roofs and insulation under tiles or waterproof materials for flat roofs – 10-12 mm
- Formwork – more than 18 mm (after consulting the engineers/builders
