Quick Details
-
Brand Name:
-
HGB
-
Model Number:
-
131.40.1250
-
Place of Origin:
-
Henan, China
-
Application:
-
slewing ring
-
Precision:
-
ABEC3-5-7-9
-
Gear:
-
internal Gear
-
Rolling element:
-
GCr5
-
Material:
-
50Mn/42CrMo/Customized
-
Operating tempereature:
-
-40°C +150°C
-
Load direction:
-
Radial bearing
-
RACEWAY hardness:
-
55~62HRC
-
Inner and outer ring modulation hardness:
-
229-268HB
-
High operational efficiency:
-
compact design
Quick Details
-
Applicable Industries:
-
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Retail, Construction works , Energy & Mining, Crane industry
-
Feature:
-
Four Point Contact
-
Seals Type:
-
NBR
-
Brand Name:
-
HGB
-
Model Number:
-
131.40.1250
-
Place of Origin:
-
Henan, China
-
Application:
-
slewing ring
-
Precision:
-
ABEC3-5-7-9
-
Gear:
-
internal Gear
-
Rolling element:
-
GCr5
-
Material:
-
50Mn/42CrMo/Customized
-
Operating tempereature:
-
-40°C +150°C
-
Load direction:
-
Radial bearing
-
RACEWAY hardness:
-
55~62HRC
-
Inner and outer ring modulation hardness:
-
229-268HB
-
High operational efficiency:
-
compact design
Why Choose Us
Product Description
Single row four point
contact ball slewing bearing
Single row cross
roller slewing bearing
Double Row
Ball slewing bearing
Three row
roller slewing bearing
Roller/Ball Combination
Slewing bearing
|
Type
|
• Single row four point contact ball slewing bearing
• Single row crossed cylindrical roller slewing bearings
• Double row ball slewing bearings
•Double row Roller/ball combination slewing bearing
•Three-Row Roller Slew Ring Bearing
|
|
Rollng elements
|
Steel ball / Cylinder Roller
|
|
Rollng elements Material
|
GCr5/GCr15SiMn/Customized
|
|
Bearing Material
|
50Mn/42CrMo/42CrMo4V /Customized
|
|
Cage Material
|
Nylon/ steel /copper
|
|
Structure
|
taper pin , Mounting holes,Inner ring ,grease fitting,load plug, seals , roller ,spacer balls or separators
|
|
Outer diameter
|
50-10000mm
|
|
Bore size
|
50-10000mm
|
|
Mounting hole
|
Through hole/Tapped hole
|
|
Raceway hardness
|
55-62HRC
|
|
Inner and outer ring
modulation hardness
|
229-269HB/Customized
|
|
Gear type
|
No gear ,Internal gear , External gear.
|
|
Embellish grease
|
EP2 lithium lubricating grease
|
|
Certificate
|
ABS.BV,DNV,ISO9001,GL
|
|
Application area
|
Ladle turret,Stacker crane,Bucket wheel machine,Solar heliostat Tracking System,port crane, Cabling machine,tower crane , offshore platform,ferris wheel, Palletizing robot,Rotary metallurgical furnace,can packing machine,Wind blade transporter,shield tunneling machine,tube push bench,excavator
|
|
Brand Name
|
HGB
|
|
Place of Origin
|
Luoyang Henan
|
|
Warranty
|
12 months
|
|
Payment term
|
T/T is our first choice
|
|
Packing details
|
1,Filling with anti-rust oil
2.Corved with Plastic paper
3.Corved with kraft paper
4.Corved with Blue tie
5.Put in wooden box
|
Product Details
Bearing Parts
Single row cross roller slewing bearing
Three row roller slewing bearing
Single row four point contact ball slewing bearing.
