Quick Details
-
Model Number:
-
FST100-DO103
-
Product name:
-
Water Dissolved Oxygen Sensor
-
DO range:
-
0...20mg/L
-
Accuracy:
-
±0.2% FS
-
Temperature range:
-
-25-130℃
-
Temperature accuracy:
-
±0.2℃
-
Signal output:
-
4-20mA
-
Withstand voltage range:
-
0-3bar
-
Working power:
-
24V12V5V
-
IP grade:
-
IP68
-
Weight:
-
0.5KG
-
Type:
-
Dissolved Oxygen Sensor
Quick Details
-
Warranty:
-
1YEAR
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Firstrate
-
Model Number:
-
FST100-DO103
-
Product name:
-
Water Dissolved Oxygen Sensor
-
DO range:
-
0...20mg/L
-
Accuracy:
-
±0.2% FS
-
Temperature range:
-
-25-130℃
-
Temperature accuracy:
-
±0.2℃
-
Signal output:
-
4-20mA
-
Withstand voltage range:
-
0-3bar
-
Working power:
-
24V12V5V
-
IP grade:
-
IP68
-
Weight:
-
0.5KG
-
Type:
-
Dissolved Oxygen Sensor
Water Dissolved Oxygen Sensor Industrial Sewage Online Detection Value Analysis Monitoring
Product Description
Product parameters
| Project name | Parameter |
| Dissolved Oxygen measurement range | 0...20mg/L |
| Resolution | 0.01mg/L |
| Dissolved Oxygen measurement accuracy | ±0.2% FS |
| Temperature measurement range | -25-130℃ |
| Temperature Resolution | 0.1°C |
| Temperature measurement accuracy | ±0.2℃ |
| Withstand voltage range | 0-3bar |
| Media flow rate | Minimum flowrate 0.02m/s |
| Shell material | PC |
| Sensitive film number | H2010 sensitive oxygen film |
| Polarization voltage | 675mV |
| Current signal output | 4-20mV(adjustable/three-wire system) |
| load | Less than 750Ω |
| Data communication | Rs485(MODBUS-RTU) |
| Working power | 24V12V5V |
| Working humidity | Relative humidity<90% |
| Process connection thread | M39*1.5 |
| Electrical connections | Direct outlet with 5 meter cable |
| Electrode protective sleeve | Include |
| Protection level | IP68 |
| Weight | 0.5KG |
