Quick Details
-
Name:
-
Customized custom quartz glass plate quartz glass sheet
-
Material:
-
99.99% Pure Quartz
-
Length:
-
5-800mm
-
Softening Point:
-
1780°C
-
Color:
-
Clear, Transparent
-
Working temperature:
-
1200°C
-
OEM:
-
YES
-
Packing:
-
Bubble film, foam, carton
Quick Details
-
Type:
-
Clear Quartz Plate
-
Application:
-
Optical Instrument
-
Place of Origin:
-
China
-
Name:
-
Customized custom quartz glass plate quartz glass sheet
-
Material:
-
99.99% Pure Quartz
-
Length:
-
5-800mm
-
Softening Point:
-
1780°C
-
Color:
-
Clear, Transparent
-
Working temperature:
-
1200°C
-
OEM:
-
YES
-
Packing:
-
Bubble film, foam, carton
Product Description
Customized custom quartz glass plate quartz glass sheet with different shape and holes
Advantage
|
Round Tpye
|
Diameter: 1mm-500mm;
Thickness: 0.5mm-300mm. |
|
Rectangle Tpye
|
Length: 5mm-2000mm;
Width: 5mm-800mm; Thickness: 0.5mm-100mm |
|
Density
|
2.2g/cm3
|
|
Compressive strength
|
1100Mpa
|
|
Young's modulus
|
72000Mpa
|
|
Modulus of rigidity
|
31000Mpa
|
|
Mohs hardness
|
5.5~6.5
|
|
Transformation point
|
1280°C
|
|
Softening Point
|
1780°C
|
|
Annealing point
|
1250°C
|
|
Specific heat (20 ~ 350 °C)
|
670J/kg.°C
|
|
Thermal conductivity (20 °C)
|
1.4W/m.°C
|
|
Index of refraction
|
1.4585
|
|
Thermal processing temperature
|
1750~2050°C
|
|
Short-term working temperature
|
1300°C
|
|
Long-term working temperature
|
1100°C
|
|
Strain
|
1270 C Fused The Quartz Glass Brick
|
|
PPM grade
|
Controlled 10/20/100 PPM
|
|
Electrical Resistivity: 1000℃
|
1x106 Ω. cm
|
|
AL
|
Fe
|
K
|
Na
|
Li
|
Ca
|
Mg
|
Cu
|
Mn
|
Cr
|
|
5-12
|
0.19-1.5
|
0.71-1.6
|
0.12-1.76
|
0.38-0.76
|
0.17-1.23
|
0.05-0.5
|
0.05
|
0.05
|
<0.05
|
|
B
|
Ti
|
|
<0.1
|
<1
|
|
mm
|
<220
|
255
|
280
|
315
|
350
|
380
|
590
|
780
|
|
%
|
89
|
91
|
93
|
93
|
93
|
93
|
93.2
|
93.4
|
Detailed Images
Packing & Delivery
Customized custom quartz glass plate quartz glass sheet with different shape and holes
Packing Details:
1. Bubble wrap;
2. Polystyrene foam sheet;
3. Carton;
4. Wooden case
Delivery time: 5-7 days by Express, UPS, DHL, FedEx, DPEX, TNT, EMS, SF.....
or shipping depending on different quantity, 15-30 days.
2. Polystyrene foam sheet;
3. Carton;
4. Wooden case
or shipping depending on different quantity, 15-30 days.
