Quick Details
-
Operating System:
-
Andriod & Windows
-
Type:
-
Tablet PC
-
Weight:
-
910g
-
Place of Origin:
-
Shenzhen
-
Brand Name:
-
Dingdata
-
Model Number:
-
S85TW
-
OS:
-
Windows 10
-
Camera:
-
5MP+13MP
-
Certification:
-
MIL-STD-810G/CE/FCC
-
Color:
-
Black
-
Storage:
-
256GB/128 GB
-
Application:
-
Industrial Automation Fields
-
Language:
-
Support Multi-language
-
Interface:
-
TF/SIM slot, USB Interface, Earphone Jack,DC Jack, HDMI
-
2D barcode engine:
-
MOTO SE4710 hardware decoding, Support Buzzer
-
Battery Capacity:
-
3.8V/10000mAh , Removable polymer li-ion battery
Quick Details
-
Screen Size:
-
8"
-
Memory Capacity:
-
8GB + 256GB
-
Display resolution:
-
1920x1200
-
Operating System:
-
Andriod & Windows
-
Type:
-
Tablet PC
-
Weight:
-
910g
-
Place of Origin:
-
Shenzhen
-
Brand Name:
-
Dingdata
-
Model Number:
-
S85TW
-
OS:
-
Windows 10
-
Camera:
-
5MP+13MP
-
Certification:
-
MIL-STD-810G/CE/FCC
-
Color:
-
Black
-
Storage:
-
256GB/128 GB
-
Application:
-
Industrial Automation Fields
-
Language:
-
Support Multi-language
-
Interface:
-
TF/SIM slot, USB Interface, Earphone Jack,DC Jack, HDMI
-
2D barcode engine:
-
MOTO SE4710 hardware decoding, Support Buzzer
-
Battery Capacity:
-
3.8V/10000mAh , Removable polymer li-ion battery
Product Description
Product Paramenters
|
Model
|
S85TW
|
|
Dimension
|
234*144*16.8mm
|
|
OS
|
Windows 10 Pro/IOT 64bit Default language：English
|
|
CPU
|
Intel JASPER LAKE N5100
|
|
Weight
|
Device unit: 800g
|
|
Display
|
8 inch IPS Capacitive touch pane, Support 10 points touch G+G
|
|
Memory
|
8GB+256GB/8GB+512GB/16GB+256GB/16GB+512GB Optional
|
|
Battery Capacity
|
5000mAh/7.6V ，Removable Li-polymer battery
|
|
Resolution
|
800*1280 IPS LCD， Minimum 1000cd/m2
|
|
Interface Configuration
|
1. Type-A: USB3.0 x2
2. HDMI: HDMI Type A x1,Audio and video output
3. RJ45 Ethernet: USB type RJ45（10/100/1000M x1）
4. 3.5mm Headphone interface: ∮3.5mm Standard headphone interface x1
5. DB9 RS232:（Mini USB type RS232）9-pin serial port x1
6. DC powerinterface: DC 12V 3A ∮4.0mm power interface x1
|
|
SIM
|
SIM card x1 in tablet
|
|
1D/2D barcode (Optional)
|
Honeywell N3680 Hardware decoder
|
|
UHF RFID Internal (Optional)
|
Output power range：18-26 dBm；Receiving sensitivity< -70dBm；Readdistance：2-3 meter
|
|
UHF RFID External (Optional)
|
Output power range：18-26 dBm；Receiving sensitivity< -70dBm；Readdistance：4-5 meter
|
|
Fingerprint module (Optional)
|
AFM60,1:N identification or 1:1 verification
|
|
High precision GNSS (Optional)
|
Module TAU1201,Sub meter level，positioning accuracy：0.25-1 seconds，Support Beidou、GPS、GLONASS；Capture sensitivity:-158 dBm； Cold
start：24seconds； Hot start：1seconds |
|
IP rating
|
IP67
|
|
Drop Resistance
|
Drop 1.2m, 6 sides, in operation status
|
|
Camera
|
Front 5.0MP，Rear 13.0MP
|
|
Extensive Slot
|
Bottom 8PIN + Back 16PIN
|
|
3G/4G
|
TDD-LTE：B40 FDD-LTE：B1/B2/B3/B4/B5/B7/B8/B28 WCDMA：B1/B2/B4/B5/B8 GSM：B2/B3/B5/B8
|
|
Operate Temperature
|
-20°C ～ 60 °C
|
|
Store Temperature
|
-30°C ～ 70 °C
|
|
NFC/RFID
|
Support NXP NFC 13.56MHz Support ISO/IEC :14443A/14443B/15693/18092/mifare ，identification distance ：4cm
|
|
Wifi
|
WIFI 802.11(ac/a/b/g/n) dual frequency 2.4G+5.8G WIFI
|
|
Bluetooth
|
BT4.2 (BLE) class1.5 Transmission distance ：10m
|
|
GPS
|
Support Beidou+GPS+glonass；Capture sensitivity:-163 dBm；Cold start：35seconds，Hot start：1seconds
|
|
Certification standards
|
Military 810G, EU CE, US FCC
|
|
Accessories
|
Standard include Power adaper with USB Cable,Hand strap, optional Docking Charger,Car Holder,Back strap,Stylus,Car Charger,etc.
|
