Quick Details
-
Brand Name:
-
KAEMI or GM
-
Model Number:
-
EP20-21
-
Voltage:
-
220V
-
Cache Capacity:
-
N/A
-
Cutter Pressure:
-
N/A
-
Cutting Speed:
-
120 ㎡/h
-
Driver:
-
Servor Motor
-
Cutting Length:
-
No Regulation
-
Repeat Cutting:
-
N/A
-
Size:
-
198*110*70cm to 270*110*70
-
Product Name:
-
CAD Paper Pattern Printing Plotter 190cm to 250cm Width Big Ink Box
-
Printing Materials:
-
White Paper,Kraft, etc
-
Cutting Size:
-
1650mm to 2050mm
-
Paper Size:
-
1700mm to 2100mm
-
Printing Tool:
-
Universal HP45 Ink Box or Cartridge
-
Ink Cartridge Type:
-
HP45 Ink Box or Cartridge 2 to 4 Printing Heads Available
-
Printing Resolution:
-
150-600DPI, Optional and Settable on Menu
-
Power Supply Voltage:
-
220V/50Hz
-
CAD File Format:
-
HP-GL
Quick Details
-
Paper Feed Width:
-
2000mm to 2600mm
-
Cutting Width:
-
1900 to 2500mm
-
Place of Origin:
-
Hubei, China
-
Brand Name:
-
KAEMI or GM
-
Model Number:
-
EP20-21
-
Voltage:
-
220V
-
Cache Capacity:
-
N/A
-
Cutter Pressure:
-
N/A
-
Cutting Speed:
-
120 ㎡/h
-
Driver:
-
Servor Motor
-
Cutting Length:
-
No Regulation
-
Repeat Cutting:
-
N/A
-
Size:
-
198*110*70cm to 270*110*70
-
Product Name:
-
CAD Paper Pattern Printing Plotter 190cm to 250cm Width Big Ink Box
-
Printing Materials:
-
White Paper,Kraft, etc
-
Cutting Size:
-
1650mm to 2050mm
-
Paper Size:
-
1700mm to 2100mm
-
Printing Tool:
-
Universal HP45 Ink Box or Cartridge
-
Ink Cartridge Type:
-
HP45 Ink Box or Cartridge 2 to 4 Printing Heads Available
-
Printing Resolution:
-
150-600DPI, Optional and Settable on Menu
-
Power Supply Voltage:
-
220V/50Hz
-
CAD File Format:
-
HP-GL
Product Description
| Technical Parameters | ||||
| Type: | Big Capacity EP20L Ink Box--Continuous Ink Supply, No Ink Box Replacement | |||
| Product Model | EP20-19 | EP20-21 | EP20-23 | EP20-25 |
| Printing Width(cm) | 190 | 210 | 230 | 250 |
| Feeding Paper Width(cm) | 200 | 220 | 240 | 260 |
Printing Speed: Two-way high speed 120 m2/h
Printing format: HPGL drawing language,compatible with domestic and foreign CAD software,special format can be customized
Print resolution: 150-600DPI
Type of Nozzle: EP20L
Line quality: Clear,smooth,no seam,optional 1-8 lines
Nozzle Cleaning: Automatic cleaning before printing
Paper Loading: Front heightening device to support paper roll with diameter of 28cm
Paper Feeding: Hidden infrared precise paper feeding system,continuous 700 meters without deviation
Receiving and Delivering Paper: Unattended automatic paper receiving and feeding
Print Media: 40-80g,ordinary roll printing paper; 80-250g,single brown paper
Communication Interface: Network port,multiple computers can separately control printing
Power Supply Voltage: 220V/50Hz
Button Panel: Press the keys operation,simple,convenient,durable
Machine Structure: Die standardized metal structure,high precision and long life
Output Center: 1.support manual or automatic printing 2.optional ink-saving mode 3.support online printing
File Format: HP-GL
Working Temperature: 10~35℃ or 50~95℉; Humidity: 15%--85% RH(With no Condentation)
Printing format: HPGL drawing language,compatible with domestic and foreign CAD software,special format can be customized
Print resolution: 150-600DPI
Type of Nozzle: EP20L
Line quality: Clear,smooth,no seam,optional 1-8 lines
Nozzle Cleaning: Automatic cleaning before printing
Paper Loading: Front heightening device to support paper roll with diameter of 28cm
Paper Feeding: Hidden infrared precise paper feeding system,continuous 700 meters without deviation
Receiving and Delivering Paper: Unattended automatic paper receiving and feeding
Print Media: 40-80g,ordinary roll printing paper; 80-250g,single brown paper
Communication Interface: Network port,multiple computers can separately control printing
Power Supply Voltage: 220V/50Hz
Button Panel: Press the keys operation,simple,convenient,durable
Machine Structure: Die standardized metal structure,high precision and long life
Output Center: 1.support manual or automatic printing 2.optional ink-saving mode 3.support online printing
File Format: HP-GL
Working Temperature: 10~35℃ or 50~95℉; Humidity: 15%--85% RH(With no Condentation)
