Quick Details
-
After-sales Service:
-
Contact the supplier to know more
-
Warranty:
-
Contact the supplier to know more
-
Type:
-
Crawler Excavator
-
Usage:
-
GM Excavator
-
Bucket:
-
Shovel
-
Transmission:
-
Mechanical Transmission
-
Drive Type:
-
Internal Combustion Drive
-
Bucket Capacity:
-
0.1~0.5m³
-
Size:
-
Small-Scale
-
Certification:
-
Other
-
Condition:
-
New
-
Payment:
-
L/C T/T D/P Western Union Paypal Money Gram Other
-
Export Port:
-
Shanghai
-
Output:
-
2000pieces/month
Quick Details
Product Description
CDM6060 G4 Main Operating Dimensions And Performance Parameters | ||
| Machine Weight | kg | 5850 |
| Bucket Capacity | m³ | 0.23-0.25 |
| Engine Model | Model | 洋马4TNV94 |
| Engine Power | kw/rpm | 35.9/2000 |
| Fuel Tank Capacity | L | 130 |
| Operating Pressure | Mpa | 26.5 |
| Hydraulic Tank Capacity | L | 80 |
| Maximum Digging Radius | mm | 5946 |
| Maximum Digging Height | mm | 5980 |
| Maximum Digging Depth | mm | 3812 |
| Maximum Dump Height | mm | 4185 |
| Maximum Digging Radius At Ground Level | mm | 5811 |
| Travel Speed (High/Low) | km/h | 4.2/2.5 |
| Swing Speed | n/min | 11.5 |
| Tail Swing Radius | mm | 1700 |
| Track Wheelbase | mm | 1900 |
| Track Gauge | mm | 1600 |
| Maximum Bucket Digging Force | kN | 40 |
| Maximum Arm Digging Force | kN | 28 |
| Transport Dimensions (L X W X H) | mm | 5671×2000×2632 |
