Quick Details
-
Model Number:
-
LFT3000
-
Accuracy:
-
0.5%FS, 0.5%FS
-
Range:
-
0~1...500mH2O
-
Output:
-
4~20mA / 0.5~4.5V / 1~5V / 0~10V
-
Output Mode:
-
Two-wired or Three-wired
-
Electrical Connection:
-
Packard, DIN43650C, DIN72585, M12, Cable
-
Pressure Connection:
-
Male G1/4, NPT 1/4, 7/16-20UNF, M20X1.5, G1/2...
Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LEFOO
-
Model Number:
-
LFT3000
-
Accuracy:
-
0.5%FS, 0.5%FS
-
Range:
-
0~1...500mH2O
-
Output:
-
4~20mA / 0.5~4.5V / 1~5V / 0~10V
-
Output Mode:
-
Two-wired or Three-wired
-
Electrical Connection:
-
Packard, DIN43650C, DIN72585, M12, Cable
-
Pressure Connection:
-
Male G1/4, NPT 1/4, 7/16-20UNF, M20X1.5, G1/2...
Products Description
Liquid Level Pressure Transmitter
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
|
A
Range
|
B
Output Mode
|
C
Measurement Unit
|
D
Accuracy Grade
|
E
Electrical Connection
|
F
Display Mode
|
G
Cable Length
|
|
0~0.5...200mH
2
0
|
A4=4~20mA(2-wired)
|
M=Meter
|
0.5=0.5%F.S
|
M= Cable Outlet
|
N=Without display
|
1.0=1m
|
|
|
VO5=0.5~4.5V(3-wired)
|
CM = Centimeter
|
|
|
D2=Explosion-proof digital display
|
2.0=2m
|
|
|
V0=0~5V(3-wired)
|
|
|
|
|
|
|
|
v1O=0~1OV(3-wired)
|
|
|
|
|
|
|
|
RS=RS-485
|
|
|
|
|
|
Specification
|
General
|
Value
|
|
|
|
|
|||||
|
Measurement Range
|
0~0.5...200mH2O
|
|
|
|
|
|||||
|
Overload Pressure
|
1.5 times ofrated pressure
|
|
|
|
|
|||||
|
Accuracy
|
±0.5%F.S
|
|
|
|
|
|||||
|
Stability
|
＜0.5% F.S/year
|
|
|
|
|
|||||
|
Working Temp
|
-20℃~85℃
|
|
|
|
|
|||||
|
Storage Temp
|
-40℃~100℃
|
|
|
|
|
|||||
|
Measured Medium
|
Liquid compatible with 304/316L stainless steel,PEPVC,Fluorine rubber or Nitrile rubber
|
|
|
|
|
|||||
|
Throw-in type Liquid Level Pressure Transmitter
|
|
|
|
|
|
|||||
|
Electrical Performance
|
2-wired
|
3-wired
|
|
|
4-wired
|
|||||
|
Output Signal
|
4~20mA
|
0.5~4.5V
|
0~5V
|
0~10V
|
RS485
|
|||||
|
Power Supply
|
8~36VDC
|
4.75~5.25VDC
|
8~36VDC
|
12~36VDC
|
10~30VDC
|
|||||
|
Digital display throw-in type liquid level pressure transmitter
|
|
|
|
|
|
|||||
|
Electrical Performance
|
2-wired
|
3-wired
|
|
4-wired
|
|
|||||
|
Output Signal
|
4~20mA
|
0-10V
|
|
RS485
|
|
|||||
|
Power Supply
|
10~30vDC
|
14~36vDC
|
|
10~36vDC
|
|
|||||
|
Electrical Connection
|
cable outlet
|
|
|
|
|
|||||
|
Pressure Connection
|
Throw-in type
|
|
|
|
|
|||||
|
Enclosure Protection
|
Ip68
|
|
|
|
|
|||||
|
Pressure Form
|
Gauge Pressure G
|
|
|
|
|
|||||
|
Certification
|
Safety explosion-proof type E,ROHS, EU electrical safety standards CE
|
|
|
|
|
|||||
①Measured at 25°C with combined accuracy of linearity, repeatability and hysteresis.
