Quick Details
-
Size:
-
optional, 80mm-500mm
-
Warranty:
-
NONE
-
Place of Origin:
-
Shanxi, China
-
Brand Name:
-
bigstars
-
Model Number:
-
1a1
-
Viscosity:
-
standard
-
Abrasive:
-
Diamond&CBN
-
Service:
-
OEM
-
Usage:
-
Surface grinding ,Internal grinding
-
Viscostiy:
-
High
-
MOQ:
-
5 Pieces
-
Certification:
-
Reach
Quick Details
-
Application:
-
Aluminum, Deburring, Ferrous Metals
-
Shape:
-
Flat-Shaped
-
Hardness:
-
standard
-
Size:
-
optional, 80mm-500mm
-
Warranty:
-
NONE
-
Place of Origin:
-
Shanxi, China
-
Brand Name:
-
bigstars
-
Model Number:
-
1a1
-
Viscosity:
-
standard
-
Abrasive:
-
Diamond&CBN
-
Service:
-
OEM
-
Usage:
-
Surface grinding ,Internal grinding
-
Viscostiy:
-
High
-
MOQ:
-
5 Pieces
-
Certification:
-
Reach
Product Description
| Mesh Size | Averrage Diameter(µm) | FEPA | U.S.A |
| 50 | 297 | D301 | 50/60 |
| 60 | 250 | D252 | 60/85 |
| 80 | 177 | D181 | 85/100 |
| 100 | 149 | D151 | 100/120 |
| 120 | 125 | D126 | 120/140 |
| 140 | 105 | D107 | 140/170 |
| 170 | 88 | D91 | 170/200 |
| 200 | 74 | D76 | 200/230 |
| 230 | 62 | D64 | 230/270 |
| 270 | 53 | D54 | 270/325 |
| 325 | 44 | D46 | 325/400 |
| 400 | 37 | M40 | 36-54µ |
| 600 | 28 | M25 | 22-36µ |
| 1000 | 15 | M16 | 12-22µ |
| 1500 | 10 | M10 | 8-12µ |
| 2000 | 8 | 5-12µ | |
| 2500 | 6 | M6.3 | 4-8µ |
| 3000 | 5 | 2-6µ |
- Wheels grinding ability and wheel life depend on the combination of bi nding material ,super abrasive mesh size, concentration, and porosity. The harder the bond, the longer wheel life is achieved.On the contrary, the softer the bond, better grinding ability is achieved because porosity becomes higher .Also higher concentration of abrasive, equates to longer wheel life.
- Automated processing is available because simultaneous operation of truing and dressing using rotary dresser on the grinding machine is possible.
- Cutting edges can be manipulated in such a manner that the surface finish of the part can be controlled.
- Diamond wheels have difficulty in truing and dressing with rotary dressers.Therefore surface finish depends on the mesh size of super abversive in the diamond wheel.
- They are efficiently used for grinding difficult-to-machine materials such as PCD,PCBN,ceramis,etc.
- They are fenerally superior in grindding ability to metal bond wheels. Because the vitrified bond has no elasticity, it is better suited for tight tolerance applications than resin bond wheels.
- They are used for grinding ferrous materials such as automotive parts(camshafts,crankshafts,gears, CVJ, etc.) , bearing parts, house hold appliance parts(compressors, motor shafts, etc.),and cutting tools.
- CBN abrasive has superior heat stability thus providing excellent performance in super high-speed grinding to process camshafts, crankshafts,etc.
Packaging & Shipping
| Packing | Carton, plastic bag,or as your request | ||||||
| Shipping | we use DHL,UPS,FEDEX,ect.to ship the goods,or according to the customer's requirement | ||||||
| Delivery time | about3-7days, for special time according to your quantity | ||||||
