Quick Details
-
Dimension(L*W*H):
-
1000x2000x4000
-
Weight:
-
17000
-
Year:
-
2017
-
Power (kW):
-
22
Quick Details
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
fineyear
-
Voltage:
-
380v
-
Dimension(L*W*H):
-
1000x2000x4000
-
Weight:
-
17000
-
Year:
-
2017
-
Power (kW):
-
22
|
Model |
TMX |
| Line speed | 5 ~ 25m/min |
| Take-up height | 900mm |
| Width of production roller |
650mm
(design according to tread width) |
| Pick-up temperature | ≤ 40ºC (Ambient temperature + 5ºC) |
| Cutter: Max. thickness of tread cutting | 20mm |
| Max. cutting width | 450mm |
| Range od cutting angle adjustment | 35° ± 5° |
| Length tolerance of the cutting component | ± 3 |
| Cutting frequency | 10 ~ 15 cuts/min |
| Pressure of compressed air | 0.6 ~ 0.8 Mpa |
| Total motor power | 23.3KW |
| Cooling water consumption | 50 ~ 60 m3/h |
| Dimension (L*W*H) | 28000*2000*2800mm |
| Weight |
20000kg
|
