Quick Details
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
Kena | Huan Neng Power
-
Dimension(L*W*H):
-
Depend
-
Weight:
-
28
-
Rated power/speed:
-
3.2/3000, 3.6/3000
-
Product Name:
-
Diesel Engine
-
Keyword:
-
Durable OHV 4-stroke Engine
Quick Details
-
Displacement:
-
247cc
-
Emission Standard:
-
Other
-
Power:
-
6HP, 12HP, 5HP, 10HP
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
Kena | Huan Neng Power
-
Dimension(L*W*H):
-
Depend
-
Weight:
-
28
-
Rated power/speed:
-
3.2/3000, 3.6/3000
-
Product Name:
-
Diesel Engine
-
Keyword:
-
Durable OHV 4-stroke Engine
Premium Engines
Product Description
| Model | HN173FB | HN178F | HN186FA | HN188FA | HN192F | HN195F |
| Type | Single-cylinder / Vertical / 4-stroke / Air-cooled / Direct injection | |||||
| Combustion System | Direct Injection | |||||
| Bore×Stroke (mm) | 73x59 | 78x62 | 86x72 | 88x75 | 92x75 | 95x75 |
| Displacement (L) | 0.247 | 0.296 | 0.418 | 0.456 | 0.499 | 0.532 |
| Compression Ratio | 20:1 | 20:1 | 19:1 | 20:1 | 19:1 | 19:1 |
| Rated Power / Speed | 3.2/3000, 3.6/3600 | 3.7/3000, 4.0/3600 | 5.8/3000, 6.6/3600 | 6.6/3000, 7.5/3600 | 7.5/3000, 8.2/3600 | 8.5/3000, 9.2/3600 |
| Max. Power / Speed | 4.3/3000, 4.8/3600 | 5.0/3000, 5.5/3600 | 7.9/3000, 9.0/3600 | 9.0/3000, 10.2/3600 | 10.2/3000, 11.2/3600 | 10.2/3000, 11.2/3600 |
| Rated Speed | 3000/3600 | 3000/3600 | 3000/3600 | 3000/3600 | 3000/3600 | 3000/3600 |
| Starting System | Manual (F) / Electric (E) | |||||
| Fuel Capacity (L) | 2.5 | 3.5 | 5.5 | 5.5 | 5.5 | 5.5 |
| Lubrication Capacity (L) | 0.75 | 1.1 | 1.65 | 1.65 | 1.65 | 1.65 |
| Fuel Consumption (L/H) | ≤1.2 | ≤1.41 | ≤2.15 | ≤2 | ≤2 | ≤2 |
| Fuel / Lubrication | 0# Diesel Fuel (Summer), 10# Diesel Fuel (Winter) / SAE 10W/30 | |||||
| Dimensions (mm) | 332x376×415 | 385x420x450 | 420×440x495 | 420x440x495 | 420x440x495 | 420x440x495 |
| N.W. (Recoil / Electric) | 28kg/32kg | 33kg/38kg | 47kg/53kg | 48kg/53kg | 50kg/55kg | 50kg/55kg |
