Quick Details
-
Type:
-
Micro-Breaking
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Class:
-
PC
-
Ceritication:
-
IEC. CE, CCC
-
Type:
-
Micro-Breaking
| Conventional thermal current IthA | 800A | 1000A | 1250A | 1600A | 2000A | 2500A | 3200A | ||
| Rated impuse withstand voltage Ui(V) | 1000V | ||||||||
| Rated Surge-resistant voltage Uimp KV | 12KV | ||||||||
| Rated Working votlage Ui(V) | AC400V | ||||||||
| Rated Working Current Ie(A) | AC-31 | 800 | 1000 | 1250 | 1600 | 2000 | 2500 | 3200 | |
| AC-33 | 800 | 1000 | 1000 | 1000 | 1250 | 1250 | 1250 | ||
| AC-35 | 800 | 1000 | 1000 | 1250 | 2000 | 2000 | 2500 | ||
| Rated making capability | 10Ie | ||||||||
| Rated breaking capability | 8Ie | ||||||||
| Rated restrict short circuit current KA | 100 | 120 | 80 | ||||||
| Rated short-time withstand current Is | 26KA | 50KA | 55KA | ||||||
| Change-over time I-O-II or II-OI(s) | 1.2S | 2.4S | |||||||
| Power supply voltage control | DC24V, 48V, 110V, AC220V | ||||||||
| The energy | Sartup | 400W | 400W | 600W | |||||
| Consumption Rated Control Voltage | In gear | 90W | 98W | 120W | |||||
| Weight(kg) | 4poles | 32 | 36 | 40 | 49 | 95 | 98 | 135 | |
