Quick Details
-
Brand Name:
-
Unisheen
-
File Max:
-
4G(FAT32) or 16G(NTFS/exFAT)
-
Model Number:
-
UR500A-Mini
-
Video Input:
-
1*hdmi 1*MMC
-
Audio Input:
-
Hdmi/Mic/Line in
-
Video Record Files:
-
MP4(H.264)
-
Audio Codec:
-
AAC
-
Storage Device:
-
TF Card or USB disk or USB SSD
-
Dimension:
-
158x70x25mm
-
Power Supply/Battery Model:
-
12V 1.5A/F550/F750/F970
-
Screen:
-
3 Inch
-
Remote Control:
-
Yes
-
Hot-Shoe Mount:
-
Yes
Quick Details
-
Power Supply:
-
12V DC/AC
-
Input Interface:
-
HDMI, VGA, CVBS, YPbPr
-
Output Interface:
-
HDMI
-
Brand Name:
-
Unisheen
-
File Max:
-
4G(FAT32) or 16G(NTFS/exFAT)
-
Model Number:
-
UR500A-Mini
-
Video Input:
-
1*hdmi 1*MMC
-
Audio Input:
-
Hdmi/Mic/Line in
-
Video Record Files:
-
MP4(H.264)
-
Audio Codec:
-
AAC
-
Storage Device:
-
TF Card or USB disk or USB SSD
-
Dimension:
-
158x70x25mm
-
Power Supply/Battery Model:
-
12V 1.5A/F550/F750/F970
-
Screen:
-
3 Inch
-
Remote Control:
-
Yes
-
Hot-Shoe Mount:
-
Yes
Product Description
| Feature | |
| Specification | |
| Video Input(Switchable) | 1xHDMI,1xVGA,1xCVBS,1xYPbPr |
| Video Resolution | 4096x2160p60,1920x1080@60P/50p,1920x1080@60i/50i/1280x720@60p/50p 720x576i/720x480i |
| Loop Out | 1xHDMI(1080p) |
| Audio | HDMI/RCA Audio/External Line In |
| Display Screen | 3 Inch |
| Remote Control | Yes |
| Screeshot in Recording | Yes |
| Playback | Yes |
| Alone Mode | |
| Record Resolution | 1920x1080/1280x720/1280x1024/1024x768 |
| Storage Device | Flash USB Drive(up to 512G),Harddisk(up to 8T),SD(up to 512G) |
| Storage File System | FAT32/exFAT/NTFS |
| Record Format | MP4(H.264 Codec) |
| Video Bitrate | Low 4MB/Mid 10MB/High 18MB |
| Audio Bitrate | 128KB |
| Size of Each File | 4G(FAT32) or 16G(NTFS/exFAT) |
| Schedule Recording | Support |
| Computer Mode | |
| Record Resolution | 1920x1080/1280x720/1280x1024/1024x768 |
| Compatible UVC/UAC | Yes |
| Comatible System | Win10/Mac OS/Linux |
| Compatibility with 3rd application software | OBS/Xsplit/Wirecast/FLME/QuickTime/VLC/Potplayer/Skype |
| Attached Software | UXplayer(separately to buy) |
| General | |
| Language | English/Chinese/Janpanese/Italian |
| Dimension (W×L×H) | 158x70x25mm |
| Package(W×L×H) | 186x145x78mm |
| Net/Gross Weight | 0.18kg/0.6kg |
| Temperature | 0-55(Work),-20-80(Storage) |
| Power/Consumption | 12V DC 1.0A/5w |
| Included in Package | |
| UR500A-M | 1pcs |
| MMC Cable | 1pcs |
| HDMI Cable 1.2M | 1pcs |
| USB Cable 0.8M | 1pcs |
| Power Adapter 12V1A | 1pcs |
| Remote Control | 1pcs |
| Manual | 1pcs |
