Quick Details
-
Mold Height(mm):
-
150 - 400 mm
-
Ejector Number:
-
27
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
33 kN
-
Theoretical Shot Volume(cm³):
-
181 cm³
-
Injection Rate (g/s):
-
82 g/s
-
Injection Weight (g):
-
111 g
-
Screw Speed (rpm):
-
1 - 220 rpm
-
Screw diameter (mm):
-
70 mm
-
Screw L/D Ratio:
-
21.5
-
Distance between Tie Bars:
-
315*315mm
-
Weight (KG):
-
12000 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
340 mm
-
Model Number:
-
HJF20
-
Brand Name:
-
HAIJIA
-
Power (kW):
-
17.25 kW
-
Plastic Type:
-
Thermoplastic
-
injection pressure:
-
147Mpa
-
Pump Motor Power:
-
5.5KW
-
Oil Tank Capacity:
-
210L
-
Machiner Dimensions(mm):
-
1.6m*1.24m*1.9m
-
max mold height:
-
160mm
-
min,mold height:
-
100mm
-
Product name:
-
blood lancet 28g Molding Machine
-
Clamping Force (kN):
-
200 kN
-
Certification:
-
CE ISO9001
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
315mm
-
Distance between Tie Bars(Height)(mm):
-
315mm
-
Plasticizing Capacity(g/s):
-
180
-
Mold Height(mm):
-
150 - 400 mm
-
Ejector Number:
-
27
-
Ejector Stroke(mm):
-
100 mm
-
Ejector Force(kN):
-
33 kN
-
Theoretical Shot Volume(cm³):
-
181 cm³
-
Injection Rate (g/s):
-
82 g/s
-
Injection Weight (g):
-
111 g
-
Screw Speed (rpm):
-
1 - 220 rpm
-
Screw diameter (mm):
-
70 mm
-
Screw L/D Ratio:
-
21.5
-
Distance between Tie Bars:
-
315*315mm
-
Weight (KG):
-
12000 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
340 mm
-
Model Number:
-
HJF20
-
Brand Name:
-
HAIJIA
-
Power (kW):
-
17.25 kW
-
Plastic Type:
-
Thermoplastic
-
injection pressure:
-
147Mpa
-
Pump Motor Power:
-
5.5KW
-
Oil Tank Capacity:
-
210L
-
Machiner Dimensions(mm):
-
1.6m*1.24m*1.9m
-
max mold height:
-
160mm
-
min,mold height:
-
100mm
-
Product name:
-
blood lancet 28g Molding Machine
-
Clamping Force (kN):
-
200 kN
-
Certification:
-
CE ISO9001
Aftersales service: Professional & timely.
Warranty
workshop
Components
Auxiliary Equipment
Customers
Company
Certifications
FAQ
Any questions, welcome to contact us, we ill be always help you and support you.
-
May I know how soon I can get the machine after I transfer the deposit?
Re:Usually, if the quantity is less than 5 units, we can finish the production in 15-20days. We will try our best to offer the machines to you as soon as possible. -
How long the product warranty period?
Re:The product warranty period is 12 months. -
How long have you engaged in this industry?
Re:We have been engaged in this industry for more than 20years, Our hot products sold at home and abroad by our own foreign trade department and some trading company. -
What kinds of Processing equipment you have?
Re:CNC laser cutting equipment, CNC plasma cutting equipment, CNC flame cutting equipment, numerical control sheet metal processing equipment, 500 tons of hydraulic press,bending machine etc.
