Quick Details
-
Weight (KG):
-
1500
-
Voltage:
-
380v 50hz 3p
-
Place of Origin:
-
Zhejiang, China, Place of Origin
-
Brand Name:
-
JKPACK
-
Dimension(L*W*H):
-
2500*1590*1620
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Machine Type:
-
Horizontal
-
Installation:
-
7 days
-
Payment item:
-
TT 40% ,60% balance
-
Factory/CNC:
-
yes
-
Keyword:
-
machine coffee
Quick Details
-
Function:
-
FILLING, Sealing
-
Packaging Type:
-
Bags, Film, Foil, Pouch, Stand-up Pouch
-
Packaging Material:
-
Plastic
-
Weight (KG):
-
1500
-
Voltage:
-
380v 50hz 3p
-
Place of Origin:
-
Zhejiang, China, Place of Origin
-
Brand Name:
-
JKPACK
-
Dimension(L*W*H):
-
2500*1590*1620
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Machine Type:
-
Horizontal
-
Installation:
-
7 days
-
Payment item:
-
TT 40% ,60% balance
-
Factory/CNC:
-
yes
-
Keyword:
-
machine coffee
Product Description
PACKING SOLUTION
The Filling System is Just for Your Reference.We Will Offer You the Best Solution According to Your Product Mobility, Viscosity, Density, Volume, Dimensions, Etc.
-
- Powder Packing Solution —— Servo Screw Auger Filler Is Specialized for Power Filling Such as Nutrients Power, Seasoning Powder, Flour, Medicinal Powder, Etc.
- Liquid Packing Solution —— Piston Pump Filller Is Specialized for Liquid Filling Such as Water, Juice, Laundry Detergent, Ketchup, Etc.
- Solid Packing Solution —— Combination Multi-head Weigher Is Specialized for Solid Filling Such as Candy, Nuts, Pasta, Dried Fruit, Vegetable, Etc.
-
Granule Pack Solution
—— Volumetric Cup Fillier Is Specialized for Granule Filling Such as Chemial, Beans, Salt, Seasoning, Etc.
——————
APPLOCATION
——————
APPLCABLE BAG TYPE
-
Product Uses
| The Main Technical Parameters | |
| Model | MR8-200/300RW |
| Bag Size | Width:80-210/200-300mm, Length:100-300/100-350mm |
| Filling Volume | 5-2500g (Depending on type of products) |
| Capacity |
30-60bags/min (The speed depends on type of products and packaging material used)
25-45bags/min (For zipper bag) |
| Package Accuracy | |
| Total Power | 2.5KW (220V/380V,3PH,50HZ) |
| Demension | 1710*1505*1640 (L*W*H) |
| Weight | 1480KGS |
| Compress Air Requirement | ≥0.8m³/min supply by user |
Technology
| Parts of Machine | ||||||||||
| Parts | PLC | Touch Screen | Frequency Conveter | Vacuum Pump | Printer | Main Motor | Temperature Controllor | Proximoty Swith | Cylinder | |
| Brand | SIEMENS | SIEMENS | TOSHIBA | ORION | SHENG LONG | EVERGEAR | AISET | OMRON | FESTO | AIRTAC |
| Oringin | Germany | Germany | Japan | Japan | China | China | China | Japan | Germany | China |
| Can replace parts as needed | ||||||||||
| Work Process | |
| Safety Measures | |
|
Station 1 Bag Feeding
Station 2 Date Printing (option)and Open zipper bag Station 3 Open bag Station 4 Filling Materials Station 5,6,7 : Vibration,Air Removal,Nitrogen Filling,Close Zipper,Hole Punching,Heat Sealing Remark:No.5.6.7.Stations are based on customer requirements for adjusting. Station 8 Heat Sealing and Product Output |
|
| Stations are based on customer requirements for adjusting. | |
