Quick Details
-
Model Number:
-
ODO1000W
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
430*230*148mm
-
Weight:
-
3.9kg
-
Rated power:
-
1000W
-
Warranty:
-
18 Months
-
Output waveform:
-
Pure Sinewave
Quick Details
-
Output Current:
-
0-30A
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ODOELEC
-
Model Number:
-
ODO1000W
-
Output Frequency:
-
50Hz/60Hz
-
Size:
-
430*230*148mm
-
Weight:
-
3.9kg
-
Rated power:
-
1000W
-
Warranty:
-
18 Months
-
Output waveform:
-
Pure Sinewave
Product Description
Applicable for
Off grid single phase safe power inverter 12v 24v 36v to 220v dc ac pure sine wave 500w 1000w 2000w 3000w
Technical parameter
|
Model
|
|
ODO-800S ODO-1000S
|
|
|
|
||||
|
Input
|
DC voltage
|
12V
|
24V
|
48V
|
110V
|
||||
|
|
Voltage range
|
10-16VDC
|
20-33VDC
|
40-63VDC
|
90-130VDC
|
||||
|
|
No load current draw
|
0.5A
|
0.3A
|
0.2A
|
0.1A
|
||||
|
|
Efficiency
|
> 90%
|
|
|
|
||||
|
|
DC connection
|
Cables with clips or car adaptor
|
|
|
|
||||
|
Output
|
AC voltage
|
100/110/120VAC or 220/230/240VAC
|
|
|
|
||||
|
|
Continuous power
|
800W
|
|
1000W
|
|
||||
|
|
Surge power
|
1600W
|
|
2000W
|
|
||||
|
|
Wave form
|
pure sine wave
|
|
|
|
||||
|
|
Frequency
|
50Hz or 60Hz
|
|
|
|
||||
|
|
AC regulation
|
3%
|
|
|
|
||||
|
Protection
|
Low voltage alarm
|
10.5DC±0.5V
|
21DC±1V
|
42VDC±1V
|
96VDC±3V
|
||||
|
|
Low voltage shut down
|
10DC±0.5V
|
20DC±1V
|
40VDC±1V
|
90VDC±3V
|
||||
|
|
Short circuit
|
Shut off output automatically
|
|
|
|
||||
|
|
Over voltage shut down
|
16±0.5V
|
33±1V
|
63±1V
|
130±3V
|
||||
|
|
Over load
|
Shut off output
|
|
|
|
||||
|
|
Over thermal
|
Shut off output automatically
|
|
|
|
||||
|
Environment
|
Work temperature
|
-10℃ ~+50℃
|
|
|
|
|
Working humidity
|
20%~90%RH
|
|
|
|
|
Storage temperature
|
-30℃ ~+70℃
|
|
|
|
Package
|
Machine size(mm)
|
300*165*85
|
335*165*85
|
|
|
|
Packing size(mm)
|
400*230*148
|
430*230*148
|
|
|
|
Net weight(kg)
|
2.7
|
3.3
|
|
|
|
Gross weight(kg)
|
3.1
|
3.9
|
|
|
|
Packing mode
|
Carton packaging
|
|
|
|
Other
|
Start
|
soft start
|
|
|
|
|
Cooling ways
|
intelligent cooling fan
|
|
|
