Quick Details
-
Voltage:
-
380V/50HZ
-
Dimension(L*W*H):
-
1226x830x1295mm
-
Warranty:
-
1 Year
-
Weight:
-
1t-22t
-
Power:
-
5.5kw
-
Certification:
-
ISO
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Yahua
-
Model Number:
-
XK-160
-
Voltage:
-
380V/50HZ
-
Dimension(L*W*H):
-
1226x830x1295mm
-
Warranty:
-
1 Year
-
Weight:
-
1t-22t
-
Power:
-
5.5kw
-
Certification:
-
ISO
Product Description
| model | XK-150 | XK-250 | XK-360 | XK-400 |
| working diameter of rolls(mm) | 150 | 250 | 360 | 400 |
| working length of rolls(mm) | 280 | 620 | 900 | 1000 |
| linear speed of front roll(m/min) | 8 | 14.9 | 17.4 | 19.3 |
| linear speed ratio | 1:1.4 | 1:1.7 | 1:1.25 | 1:1.27 |
| max roll gap(mm) | 10 | 10 | 10 | 10 |
| gap regulating mode | manual | manual | manual | manual |
| batch capacity(kg/batch) | 1-2 | 10-15 | 20-25 | 25-35 |
| main motor power(kw) | 7.5 | 18 | 30 | 37 |
| speed reducer | worm-gear | ordinary or hardend-gear | ordinary or hardend-gear | ordinary or hardend-gear |
| overall size(mm) | 1080x796x1415 | 3400x1350x1500 | 3940x1780x1740 | 4250x1850x1870 |
| weight(kg) | 1100 | 3500 | 5670 | 7600 |
| type | XK-450 | XK-550 | XK-560 | XK-660 |
| working diameter of rolls(mm) | 450 | 550 | 560 | 660 |
| working length of rolls(mm) | 1200 | 1500 | 1530 | 2130 |
| linear speed(m/min) | 24.5 | 27.2 | 27.7 | 28 |
| linear speed ratio | 1:1.27 | 1:1.29 | 1:1.12 | 1:1.24 |
| max roll gap(mm) | 15 | 15 | 15 | 0.5-15 |
| gap regulating mode | manual or electric | manual or electric | manual or electric | manual or electric |
| batch capacity(kg/h) | 25-50 | 50-60 | 50-65 | 165 |
| main motor power(kw) | 55 | 90/110 | 90/110 | 240 |
| speed reducer | ordinary or hardend | ordinary or hardend | ordinary or hardend | ordinary or hardend |
| overall size(mm) | 5200x2380x1770 | 6260x2330x1750 | 6290x2330x1780 | 7280x3400x2530 |
| weight(kg) | 13000 | 20000 | 20400 | 47000 |
