Quick Details
-
Brand Name:
-
DEBO
-
Model Number:
-
DB-680A3
-
Binding width:
-
420mm (A3 size)
-
Max binding thickness:
-
60mm
-
Machine dimension:
-
1600*530*950mm
-
Binding speed:
-
Manual: 200-250 books/hour;Auto:250-300 books/hour
-
Cover thickness:
-
70P-250P
-
Rail:
-
Dual rail
-
Milling cutter:
-
Small milling cutter+sun milling cutter
-
Clamping mode:
-
Automatic detecting by magic eye
-
Glue melting time:
-
35 Mins
-
Driver parameter:
-
220V/50HZ 220V/50HZ// 2.8KW
Quick Details
-
Type:
-
Glue Binding Machine
-
Power:
-
Electricity
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
DEBO
-
Model Number:
-
DB-680A3
-
Binding width:
-
420mm (A3 size)
-
Max binding thickness:
-
60mm
-
Machine dimension:
-
1600*530*950mm
-
Binding speed:
-
Manual: 200-250 books/hour;Auto:250-300 books/hour
-
Cover thickness:
-
70P-250P
-
Rail:
-
Dual rail
-
Milling cutter:
-
Small milling cutter+sun milling cutter
-
Clamping mode:
-
Automatic detecting by magic eye
-
Glue melting time:
-
35 Mins
-
Driver parameter:
-
220V/50HZ 220V/50HZ// 2.8KW
Product Description
| Perfect book binding machine | ||||
| Model | 680A4 | 940A4 |
960A3
|
680A3 |
| Side Glue tank | NON | YES | YES | NON |
| YES | YES | YES | YES | |
| Binding size | 80mm to 320mm | 80mm to 420mm | ||
| Biniding thickness | 60mm(2.4inch) | |||
| Speed | Manual 200/250 books/hour | 250/400 books/hour | ||
| Auto 250/300 books/hour | ||||
| Book cover thickness | 70-250p | |||
| Rail | Dural guid | |||
| Runing model | Cover tray in the right side, book pages in the left side | |||
| Display | Touch pade screen | |||
| Glue melt time | About 20 mintues | |||
| Milling cutter | Sun (20 pcs)+Small cutter (2 pcs) | |||
| Clamp mode | Magic eyes with motor | |||
| Power | 220V/50HZ 1.2KW | 220V/50HZ 2.65KW | 220V/50HZ 2.8KW | 220V/50HZ 1.6KW |
| Machine size | 125*53*95CM | 125*53*95CM | 160*53*95CM | 140*52*97CM |
| Packing size | 160*50*98CM | 160*50*94CM | ||
| WEIGHT | 175kgs | 189kgs | 228kgs | 200kgs |
