Quick Details
-
Brand Name:
-
SMARTS
-
Model Number:
-
SMT-036-060VW
-
Output Frequency:
-
47-63Hz
-
Output Current:
-
1.67A
-
outer case:
-
Aluminum Housing
-
IP rate:
-
IP67
-
working mode:
-
constant voltage type
-
Weight:
-
550g
-
Size:
-
190*48*34mm
-
Certificate:
-
ETL,CE,ROHS
-
Warranty:
-
2 year warranty
-
Protection:
-
Short Circuit , over load ,over voltage, over temp
-
Efficiency:
-
>82%
-
Name:
-
24v 36v dc 60w led power supply
Quick Details
-
Input Voltage:
-
100-265vac
-
Output Voltage:
-
36V
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
SMARTS
-
Model Number:
-
SMT-036-060VW
-
Output Frequency:
-
47-63Hz
-
Output Current:
-
1.67A
-
outer case:
-
Aluminum Housing
-
IP rate:
-
IP67
-
working mode:
-
constant voltage type
-
Weight:
-
550g
-
Size:
-
190*48*34mm
-
Certificate:
-
ETL,CE,ROHS
-
Warranty:
-
2 year warranty
-
Protection:
-
Short Circuit , over load ,over voltage, over temp
-
Efficiency:
-
>82%
-
Name:
-
24v 36v dc 60w led power supply
Product Description
| SPECIFICAION | |||||
| MODEL | SMT-012-060VW | SMT-024-060VW | SMT-036-060VW | ||
| OUTPUT | DC VOLTAGE | 12V | 24V | 36V | |
| RATED CURRENT | 5.0A | 2.5A | 1.66A | ||
| CURRENT RANGE | 0~5.0A | 0~2.5A | 0~1.66A | ||
| RATED POWER | 60W | 60W | 60W | ||
| RIPPLE&NOISE(max) | 1.2V | 1.2V | 1.2V | ||
| voltage TOLERANCE | 12V±5% | 24V±5% | 36V±5% | ||
| SETUP RISE TIME | 80ms/110,220VAC | 80ms/110,220VAC | 80ms/110,220VAC | ||
| HOLD UP TIME(Typ.) | 60ms/110,220VAC | 60ms/110,220VAC | 60ms/110,220VAC | ||
| INPUT | VOLTAGE RANGE | 90~135/170~265Vac | 90~135/170~265Vac | 90~135/170~265Vac | |
| FREQUENCY RANGE | 50~60Hz | 50~60Hz | 50~60Hz | ||
| POWER FACTOR(Typ.) | |||||
| EFFICIENCY(Typ.) | >84% | >84% | >84% | ||
| AC CURRENT(Typ.) | 0.5A/110V,220VAC | 0.5A/110V,220VAC | 0.5A/110V,220VAC | ||
| INRUSH CURRENT (Typ.) | COLD START 30A/110,220VAC | ||||
| PROTECTION | Short circuit | Protection type:recovers automatically after condition is removed | |||
| Overload | overload protected@145-160% above peak rating | ||||
| Over temperature | Protection type:Shut down o/p voltage,re-power on to removed | ||||
| ENVIRONMENT | WORKING TEMP. | -30~+50℃ (Refer to output load derating curve) | |||
| WORKING HUMIDITY | 20~99% RH non-condensing(Waterproof) | ||||
| STORAGE TEMP.,HUMIDITY | -40~+80℃,10~99%RH | ||||
| SAFETY&EMC | SAFETY STANDARDS | ETL, CE Mark(LVD),IP67 | |||
| WITHSTAND VOLTAGE | I/P-O/P:1.5KVAC IP-GND:1.5KVAC | ||||
| EMC Test Standards | EN55015:2006;EN61547:1995+2000;EN61000-3-2:2006 | ||||
| EN61000-3-3:1995+A2:2005;EN61346-1:2001;EN61347-2-13:2006 | |||||
| NOTE | |||||
