Quick Details
-
Ejector Stroke(mm):
-
170 mm
-
Ejector Force(kN):
-
90 kN
-
Theoretical Shot Volume(cm³):
-
1061 cm³
-
Injection Rate (g/s):
-
246 g/s
-
Injection Weight (g):
-
966 g
-
Screw Speed (rpm):
-
0 - 180 rpm
-
Screw diameter (mm):
-
65 mm
-
Screw L/D Ratio:
-
21
-
Distance between Tie Bars:
-
530mm*530mm
-
Weight (KG):
-
13500 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
635 mm
-
Model Number:
-
FHG360
-
Brand Name:
-
Fuhong
-
Power (kW):
-
21.4 kW
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
-
Injection pressure:
-
182mpa-247mpa
-
Mould thickness:
-
290mm-680mm
-
Ejector stroke:
-
170mm
-
Ejector force:
-
90kn
-
Heating power:
-
21.4kw
-
Machine dimension(L*W*H):
-
7.2m*2m*2.4m
-
Machine weight:
-
7ton
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
670mm
-
Distance between Tie Bars(Height)(mm):
-
670mm
-
Mold Height(mm):
-
290 - 680 mm
-
Ejector Stroke(mm):
-
170 mm
-
Ejector Force(kN):
-
90 kN
-
Theoretical Shot Volume(cm³):
-
1061 cm³
-
Injection Rate (g/s):
-
246 g/s
-
Injection Weight (g):
-
966 g
-
Screw Speed (rpm):
-
0 - 180 rpm
-
Screw diameter (mm):
-
65 mm
-
Screw L/D Ratio:
-
21
-
Distance between Tie Bars:
-
530mm*530mm
-
Weight (KG):
-
13500 kg
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
635 mm
-
Model Number:
-
FHG360
-
Brand Name:
-
Fuhong
-
Power (kW):
-
21.4 kW
-
Plastic Type:
-
Thermoplastic
-
Automatic:
-
Yes
-
Injection pressure:
-
182mpa-247mpa
-
Mould thickness:
-
290mm-680mm
-
Ejector stroke:
-
170mm
-
Ejector force:
-
90kn
-
Heating power:
-
21.4kw
-
Machine dimension(L*W*H):
-
7.2m*2m*2.4m
-
Machine weight:
-
7ton
